Measuring draw angles
Ajuste de pantallaEl ajuste de pantalla se aprecia al ver el vídeo en pantalla completa. Elige la presentación que más te guste:
How to use a protractor to measure draw angles
Hello! My name is Maria Miller from MathMammoth.com. In this video we're
00:00:00
going to study about measuring angles. And now, if you watched my other video, you
00:00:04
hopefully remember how I showed that an angle has two rays and then you open it
00:00:10
up. The two rays are the two sides of the angle. You can open it up like this and
00:00:15
then it will be tracing a circle, an arc of a circle like this, okay? And to
00:00:20
measure angles people have agreed that the full circle would be 360 degrees and
00:00:26
so if your angle opens up, let me show you, if your angle opens up at the zero
00:00:32
angle and goes all the way over here then that would be 360 degrees. If it
00:00:38
just goes half that way to a straight angle then that's 180 degrees and if it
00:00:47
goes up this much, it is 90 degrees, the right angle, okay? And so we measure the
00:00:54
angle comparing to the full circle. If it opened up to a full circle, it would be
00:01:01
360 degrees. Then if it opens up less than that, we just compare how much of
00:01:07
the circle it has drawn here or traced here, okay? Compared to the full circle.
00:01:12
That's how angles are measured. We use a protractor to measure angles because it
00:01:18
has usually half a circle here marked and it has the numbers for the degrees.
00:01:23
Mine has two sets of numbers and that's usually the case. One set of numbers
00:01:31
starts here at zero, goes 10, 20, 30, 40, 50, etc. down over here to 180 and the
00:01:36
other set of numbers starts here at zero and goes all the way here to 180. Okay? So
00:01:42
So let's say we want to measure this angle. To do that, I need to position the vertex
00:01:50
of this angle here in my protractor in a certain point. Okay? Now remember that zero is here.
00:01:56
For my protractor, zero is here. And here is my zero line, so to speak. In your protractor,
00:02:03
this might be the zero line. You have to check if the zero is actually here. And then it
00:02:10
that's going up with the numbers. And find your zero line, and in your zero line there's
00:02:14
usually a little mark, maybe a little circle or something, where you need to
00:02:21
position the vertex. In mine there is none, but I know that it's the midpoint
00:02:24
here with the number 15. This midpoint here I need to position to the vertex.
00:02:28
And then I need to line up my zero line with one of these. Okay, like this. Now
00:02:33
it's ready for measuring. And then this is how much my angle has opened, see? From
00:02:46
here to here. And so I read now over here on the arc of the circle, it is very near
00:02:52
either 70 or 110 degrees. But you need to know which one, right? Well, here was 0. So
00:03:00
I read the numbers that are 0, 10, 20, 30, 40, etc. I read the lower numbers on mine
00:03:07
and come to 70. And this is just a tad more than that, 71 degrees, okay. And most
00:03:12
protractors have marks here, so you can see the individual degrees. This one just
00:03:20
goes by fives, each five is marked. Let's measure this angle too. So remember I
00:03:26
need to line up one of these with my zero line, but this doesn't work, okay. Now
00:03:32
this, okay, this can work, yes. And the vertex has to be put exactly in this
00:03:41
middle point here. For me it is like the number 15 there. Line up and okay.
00:03:47
And now you can imagine the angle open from here to here, right? So this is how
00:03:54
much of the circle it traces. And I again go with these numbers 10, 20, 30
00:03:58
something. This is my 35 and so it is 37 degrees. Now let's say we have to draw an
00:04:02
angle. Draw a 36 degree angle. Okay, it will be very close to this size. To start out,
00:04:11
just draw a line. It's going to be the one side of your angle, okay? There. And now mark
00:04:18
your vertex there. So if this is my vertex, then it's going to open up maybe somewhere
00:04:26
there, okay? Like this much. Something like this and this. And now I do the same as if
00:04:31
If I was measuring the angle, I need to line up this with my zero line here, and the vertex
00:04:37
with the correct point, like that.
00:04:42
Now we'll mark over here where it's 36 degrees, there's 30, 35 and a little over there, okay,
00:04:46
36 degrees.
00:04:53
And then I use that mark and just draw a line, the other side of my angle, there.
00:04:54
Now here's draw a 155 degree angle.
00:05:02
Now, if you think of this, it's gonna start here, go up to 90 and past 90 over there,
00:05:07
somewhere here.
00:05:13
It's an obtuse angle.
00:05:14
We call angles that are more than 90 degrees, less than 180, over here somewhere, obtuse
00:05:15
angles, which means like a dull type of angle, whereas these that are less than 90 are called
00:05:21
acute angles.
00:05:27
Acute angles, think of it as a sharp angle, sharp point that could come to you and, you
00:05:28
or cut you or whatever, whereas the dull type of angle, like here, obtuse angle, won't hurt
00:05:36
so much if you were hit with an object with a dull angle.
00:05:42
So to draw it, I have to first start out by drawing a line again, okay?
00:05:46
And now I know that my angle is going to open up from here, up to 90, and some more.
00:05:53
It's going to be somewhere here, right?
00:05:57
So again, position the zero line of your protractor with the line you drew, and then the midpoint
00:06:00
And now I have to go past 90 to 100, 110, all the way to 150, 155, over here, and draw a mark, and then draw my line.
00:06:07
There.
00:06:20
So this angle here is the 155 angle, or it would have traced an arc of a circle from here.
00:06:21
We often mark the arc of a circle here, just a little arc of a circle, okay?
00:06:30
This is traced arc of a circle up to here, but people often mark it nearer the vertex, like that.
00:06:34
Lastly I have a triangle, and let's try to measure its angles.
00:06:40
First angle here, it's easy, it's an acute angle, maybe about 40 degrees.
00:06:44
I put my protractor like this, and read from here, this was 0, 10, 20, 30, 40.
00:06:52
See, it's almost 50. Okay, 48 degrees, I would say.
00:07:02
Next angle. Now, this is where students have difficulty, is placing the protractor just right.
00:07:08
You know, where do you put it now? You know, okay, this has to be lined up with one of the sides.
00:07:14
But do you line up it like this? Or where, you know?
00:07:20
You need to remember, this midpoint has to be put to the vertex, but not like this.
00:07:24
because then you can't see where the other side hits or touches where you're measuring the angle.
00:07:28
It needs to be turned like this, for example.
00:07:36
And there's two ways I can do it. I can put it like this.
00:07:40
Okay? Vertex at the middle and then the real line here.
00:07:44
Or I can line up my zero line with this side of the angle like this.
00:07:48
Two ways to do it for each angle.
00:07:53
So if I do it like this, here's my zero line, and think of opening the angle.
00:07:56
It opens a little bit past 90 degrees, so this is an obtuse angle, okay?
00:08:02
It's that here, over there.
00:08:06
So 0, 10, 20, go past 90, 100, 110.
00:08:08
You see, it's between 100 and 110.
00:08:12
And so, 106.
00:08:14
And here again, okay, it might be difficult.
00:08:20
You see, oh, this won't work.
00:08:23
Can you see why?
00:08:26
How about this way?
00:08:32
Now, yes, it will work, okay? This is an acute angle. It's not very much. This is
00:08:33
my zero line and it opens up only this far. So from zero, I'm sorry, from zero I
00:08:43
go now with these top numbers 10, 20, 30. Almost 30 degrees, maybe 28. Okay, and now
00:08:53
you probably know that the angles in a triangle have to add up to 180 degrees.
00:09:05
Maybe you don't know it, but those of you who know it might notice that my numbers
00:09:10
don't add up to 180, okay? Because 8 plus 8 is 16, plus 6 is 22. But that is
00:09:14
because it is so difficult to measure so accurately, to get just, you know, maybe in
00:09:20
reality this is 47 and a half degrees and I rounded it up. Maybe this is only
00:09:27
27 degrees or whatever. It's hard to measure accurately, so don't be alarmed
00:09:31
if some of your angle doesn't get exactly 180 degrees.
