Virtual Reality
Ajuste de pantallaEl ajuste de pantalla se aprecia al ver el vídeo en pantalla completa. Elige la presentación que más te guste:
NASA Destination Tomorrow Segment explaining how NASA uses virtual reality environments to simulate NASA missions.
The great poet Walt Whitman once said, I accept reality and dare not question it.
00:00:00
Well, if old Walt was here to see this, he just might question it.
00:00:10
Today, NASA researchers are working in high-tech virtual reality simulation labs
00:00:14
using numbers, graphics, mathematical models,
00:00:19
to create three-dimensional images of objects and environments.
00:00:22
Man, it's like working inside a real holodeck.
00:00:26
Now, I spoke with Dr. Chris Sandridge at NASA Langley's Immersive Design and Simulation Lab,
00:00:28
better known as the CAVE, to find out how it works.
00:00:33
What we're standing in right now is called a CAVE.
00:00:36
It stands for Cave Automatic Virtual Environment.
00:00:39
Basically, it's a multi-screen theater where we can generate 3-D images, 3-D sounds,
00:00:42
and simulate various NASA missions.
00:00:47
The CAVE has three walls made of 10-foot by 10-foot rear projection screens
00:00:50
and a floor that is projected from above,
00:00:54
giving the users a near-complete immersion in computer-generated graphics.
00:00:56
The simulation looks like double images until you put on the goggles
00:01:00
that gives everything a three-dimensional quality.
00:01:03
The hardware and graphics equipment used to operate the system
00:01:06
were first developed for use in computer games and in the theme park industry.
00:01:09
So, how does this virtual environment work?
00:01:13
We need the glasses to describe that.
00:01:15
Basically, what we have here are shutter glasses,
00:01:18
and what they do is they kind of decode the stereo image so that we see the depth.
00:01:22
Basically, the computer is generating two images,
00:01:27
one for your left eye, one for your right eye,
00:01:30
and then there's a little sensor here on the glasses
00:01:32
that is detecting an infrared signal from behind the screen
00:01:34
that synchronizes the glasses so you see a 3-D image.
00:01:38
In addition, the person who's actually running the CAVE is also being head-tracked.
00:01:42
There's a black box above us that is putting out an electromagnetic field
00:01:46
that's being picked up by this antenna,
00:01:50
and then that relays information back to the computer
00:01:52
and tells the computer where the person is looking and what his head orientation is,
00:01:55
and then it updates the visuals and it updates the sound based on this person's position.
00:01:59
And then finally, because we don't have a mouse and a keyboard available to us,
00:02:05
we need some type of an input device.
00:02:10
So, what we have here is the wand that we use to control the application.
00:02:12
It has joysticks on it. It has some buttons.
00:02:17
And then also, it is tracked as well,
00:02:20
so the computer knows where the position of this is so we can interact with the environment.
00:02:22
So that's basically how it works.
00:02:27
And then, of course, there's kind of a supercomputer in the back room that's kind of driving it all.
00:02:29
So, can you show me how this application works?
00:02:34
Sure. Put your glasses on and then we'll go to town.
00:02:36
Got it, man. Test drive this thing.
00:02:40
This is a full-up configuration of the station,
00:02:42
and we're using this application basically for two different environments,
00:02:45
the radiation environment and the sound environment.
00:02:49
Currently, NASA Langley researchers are developing tools
00:02:52
to help design improved radiation shielding and reduce noise for the International Space Station.
00:02:55
They're able to move equipment or install shielding in the virtual reality image
00:03:00
and then observe and store calculations of what effects the changes make.
00:03:04
The simulations can be shared with other researchers at distant locations via computer network connections.
00:03:08
So, Johnny, you want to try giving it a shot?
00:03:13
Absolutely. Let me see this.
00:03:15
Take the wand.
00:03:16
Okay.
00:03:17
You need to put it on these glasses because these are the ones that are tracked.
00:03:18
All right. Thank you.
00:03:21
And the way it works is that you point the wand in the direction you want to go
00:03:24
and then push the joystick forward.
00:03:29
Forward.
00:03:30
To go forward.
00:03:31
Oh, man.
00:03:32
And you pull it backward to go backwards.
00:03:33
And then rotating is pulling the joystick left and right.
00:03:34
Check this out.
00:03:37
You might want to back out so you can see, fly around the station.
00:03:38
I'm going to throw up.
00:03:41
All right. Here we go.
00:03:42
Rookie driver.
00:03:45
Yeah.
00:03:46
Here, take the wheel.
00:03:47
Here, your glasses back.
00:03:48
Thanks.
00:03:49
I'll take these.
00:03:50
So what are some of the other uses for this technology?
00:03:51
Another use that we're just starting to work on is to develop a simulation
00:03:54
to evaluate community noise of jets and aircraft flying near airports
00:03:58
to look at how we can quiet the aircraft
00:04:04
and be less intrusive to the neighbors around the airport.
00:04:08
And then finally, I guess, these types of cave environments are used
00:04:12
by the automotive industry to lay out the interior cockpit of the car.
00:04:16
So in a virtual environment, they'll look at, like, where the mirror is,
00:04:20
where the console is, anything where human factors are involved,
00:04:24
and you can put it in actual size and look at it in the correct perspective
00:04:28
before you build hardware prototypes, which are fairly expensive.
00:04:33
This was a lot of fun.
00:04:37
This was really something else, and thanks a lot for everything.
00:04:38
Yeah, no problem.
00:04:40
One more question?
00:04:41
Sure.
00:04:42
Can I keep the glasses?
00:04:43
Yeah, everybody wants the glasses.
00:04:44
They are very exciting.
00:04:45
Check these out, man.
