In this worksheet, we are going to draw the window for the labor assignment.
00:00:04
So on this page, you will find this square, the rectangle.
00:00:13
So this rectangle's size is, you can read it here, is an A4.
00:00:20
okay so and in this case you have the midpoint here and at the bottom already marked okay so
00:00:28
we are going to connect these two points with
00:00:41
a slight line we don't need the whole of it okay so i'm just going to mark
00:00:52
because we are going to need it later here a line and here below
00:01:03
So, just there below, I'm going to mark here just a very soft line, okay?
00:01:17
Because we are going to need later the midpoint.
00:01:32
Good.
00:01:36
Here below, we are going to mark 10 millimeters,
00:01:37
because we need a parallel line to the bottom, to the side of the paper,
00:01:42
at 10 millimeters so if you have an a4 imagine this is the side of the paper okay and if you
00:01:50
have this rectangle you leave 10 millimeters up so we connect these two points at 10 millimeters
00:01:59
that's it and we are going to leave 17 millimeters from the margin this is for a4 okay if you have
00:02:10
an a4 plus you will need 23 okay so now we are going to mark here we are going to mark
00:02:26
From the side of the paper, if you have an A4, you need 17, 1.7, okay?
00:02:45
And on the other side, you will need the same, 1.7, okay?
00:02:58
Great.
00:03:11
now this we will erase this later okay but from this mark at 10 millimeters we need another 13.5
00:03:11
Okay, so from this point up, you need 13.5.
00:03:35
Okay, that is 13.5.
00:03:48
And on the other side, we are going to do the same.
00:03:53
So from the mark of 10, we need another 13.5.
00:03:58
okay great we are going to connect these two points something like that there okay so this
00:04:08
height is 13.5 okay good um anyway the measurement you have on the on the aula virtual
00:04:30
okay on the assignment on the aula virtual you have all the measurements in case you forget
00:04:45
one of them okay anyway i'm going to mark here you don't have to do it on your
00:04:50
on your page but this is going to be 17 or 23 if you have an a4 plus
00:04:57
that is the idea and here you are going to leave 10 that is the idea okay great
00:05:11
so in order to close the rectangle we need we are going to mark again 17 here and 17 on the other
00:05:22
side 17 there we are going to connect everything up and we will close we will close our rectangle
00:05:38
So, you can see here that it's 10 millimeters from above, from the side, from the lower side of the paper, 17 from both margins, and 13.5 total height, okay?
00:06:01
So, this height is going to be 13.5, okay, millimeters.
00:06:21
good so here we have the rectangle once we have that we are going to draw
00:06:33
parallels inside this rectangle five millimeters from three of the sides not
00:06:41
the top one but the other three okay so we are going to measure again five
00:06:48
millimeters on the right side five here below five again here in the corner five
00:06:54
again on the other corner the same 5 5 and in this corner 5 again and here we
00:07:15
placed before the midpoint of the whole segment there that is the midpoint so we
00:07:40
are going to need here on the middle okay we are going to need another five
00:07:49
millimeters column so here I'm going to measure from the midpoint I'm going to
00:07:55
zoom a little bit so I will place 2.5 and 2.5 to each side and there on top
00:08:05
you place a midpoint you can measure if you need and we are going to place
00:08:21
measure 2.5 2.5 there okay so again we have used the midpoints there on top and
00:08:31
And at the bottom, we connect and we place this midpoint and that midpoint.
00:08:47
Okay, so I'm going to outline everything out, connecting five millimeters apart from the different sides.
00:08:54
so you have you get parallel lines five millimeters apart from the previous
00:09:08
rectangle there this one and this one so that is the final appearance of the
00:09:23
first part so we got the previous rectangle and inside five millimeters
00:09:44
five millimeters up five millimeters in and here using the midpoints five
00:09:52
millimeters centered that is really important okay great I have named these
00:10:00
six points with letters so we understand each other explaining the procedure
00:10:09
so right now we are going to draw the two first arches to do that you're going to use
00:10:16
these centers so we are going to need a first so you place a compass on a
00:10:27
and we are going to draw two arches passing through D and C so first couple
00:10:38
of arches go from A to D and then we change to C okay they are parallel and
00:10:52
and they share the same sensor.
00:11:08
Then we are going to switch to D.
00:11:12
I'm going to get a little bit closer.
00:11:17
So I'm going to go to D, place the compass on D,
00:11:21
and you draw the symmetric arc.
00:11:27
And from D you change the radius to A
00:11:31
And do the same
00:11:36
So you will get this first window
00:11:42
You close the first couple of arches
00:11:47
So we have used A for these two arches
00:11:51
Passing through C and D
00:11:57
And D for these two arches
00:11:59
Passing through A and B
00:12:02
We are going to repeat the same procedure there, in the other side, but in this case we are going to use C and F.
00:12:04
So you place the compass on C first, so C to F, C to F, to F, draw the first arc, change the radius to E, but don't change the center, the parallel one, that's it.
00:12:20
Okay, now you change center to F and repeat. So F, C, till it crosses the previous one over there, and change the radius, not the center, F, D, F, D, you have to be accurate here, and draw the parallel line.
00:12:55
okay so we have twin arches like this okay great for the bigger arches you need a big compass
00:13:32
with a small one you would you wouldn't be able to do this so you are going to cover
00:13:47
from F to A, okay, so from F, sorry, from F to A, and you draw this big arc, okay, so, sorry,
00:13:54
I made a mistake, so I'm going to repeat, F, A, F, A, you draw this arc, with the same radius you
00:14:22
change to a F and do the same a F same radius again like this so you have the
00:14:35
bigger arc and you're going to change the radius to a e a e this compass doesn't
00:14:54
work that well so so a e sorry again a e that's it a e and f b with the same radius f b you draw
00:15:19
the parallel arc. Good. So for these two parallel arches, just for you to have it clear, you
00:15:58
use this center for these two, passing through these two points, and you use F for these
00:16:12
two arches, passing through A and B.
00:16:20
Okay, and for the last part, we are going to place here the circles.
00:16:26
In order to do that, you are going to place the midpoint of this segment, of the segment BC, the midpoint.
00:16:32
If you did it right, here you have 8 centimeters.
00:16:43
So you are going to place the midpoint, that is 4.
00:16:49
okay so but by my advice is that you measure everything up because maybe you have or you
00:16:53
have here a little mistake you could also do the segment by sector that you should do by now
00:17:02
and that you should know by now sorry of the segment bc okay but this is again the midpoint
00:17:10
okay four of eight and that distance with a compass you are going to take the distance
00:17:18
we are going to name this point m for example you don't need to to name the
00:17:31
or to write on the letters okay because you are going to erase it
00:17:39
of them later so don't name it i'm naming them for you to understand so i'm taking
00:17:44
the distance fm and this distance you transport carefully here
00:17:55
so again fm you transport with the compass if you don't have a big compass
00:18:04
you could also use the ruler you can measure this distance that is 13.1 in my case and I'm
00:18:12
transporting up the same distance okay this way you will get here the center
00:18:24
O of the future circles so to know the radius of the circles you want to draw
00:18:32
you are going to connect A with O okay so AO and we are going to draw here a
00:18:44
line that connects A, O and these two points. These two points are going to be
00:18:58
the tangency points. So if you take now the compass you can draw one arc passing
00:19:08
through tangent to the arches first circle okay and second circle that is the
00:19:27
other circle that's it okay center there passing through the two points and that's it
00:19:50
