NASA Connect Segment involving students in an activity that investigates how surface conditions influence the coefficient of friction between two surfaces.

Más información Transcripción

Descargar la transcripción

We have just seen the tip of the iceberg regarding the amazing research, researchers and research 00:00:00
tools. 00:00:06
It makes me wonder though what other new technologies are under development for reducing icing hazards. 00:00:07
But you know what, now is the time to put you to work. 00:00:12
Coming up is a high school student who has spent the summer at NASA Langley in a nine 00:00:16
week mentorship working closely with Tom Yeager. 00:00:20
John has prepared a special hands on, minds on activity which a group of students will 00:00:23
demonstrate. 00:00:28
Following the program, you are encouraged to replicate the same investigation. 00:00:29
I spent nine weeks in a NASA program for high school students called SHARP. 00:00:35
Under this program, I had the opportunity to work with Mr. Yeager. 00:00:39
I learned a great deal about the research being done on runway friction, tire designs 00:00:42
and new types of runway surfaces to minimize bad weather effects. 00:00:47
I have to admit, I was a little nervous at the beginning just because I wasn't sure if 00:00:50
I knew enough math and science to be able to grasp the research and to be able to help 00:00:54
out in the evaluation of the research data. 00:00:58
But I did okay. 00:01:01
I found that the math I had taken in middle school and high school gave me a good foundation 00:01:03
that I could build on. 00:01:06
With the help of two undergraduate students that I worked with during the summer, Brian 00:01:08
and Jonathan, I have a simple experiment that I would like you to try. 00:01:12
In this experiment, you will investigate how surface conditions influence the coefficient 00:01:16
of friction between two surfaces. 00:01:20
Your surfaces will include a ruler, sandpaper and objects found in the classroom. 00:01:22
Now, my friends and I did an experiment similar to the one you're about to do, but it was 00:01:26
a little more complicated and involved a little more math. 00:01:31
This experiment has been recreated on the Connect to Plane Weather website, so you might 00:01:33
try this with your friends or your family following the program. 00:01:37
Enough said. 00:01:41
Let's get started. 00:01:42
The math formula you will need in doing your experiment looks like this. 00:01:43
Friction coefficient equals height divided by length. 00:01:47
The following materials were collected for our experiment. 00:01:52
Three metric rulers, at least one of the rulers had to be plastic, a sheet of sandpaper 00:01:55
large enough to cover a ruler, and four objects to test, a rubber eraser, a large metal paper 00:01:59
clip, a plastic film canister top, and a small dice. 00:02:05
John helped us identify the dependent and independent variables for our experiment. 00:02:09
The independent variable, which is what we would be changing, is the ruler surface. 00:02:13
We used a plastic ruler to simulate a smooth runway surface and then a ruler covered with 00:02:17
sandpaper to simulate a rough runway surface. 00:02:22
The dependent variable for the experiment was the classroom object. 00:02:25
Before doing our test, we talked about how each object was alike and different. 00:02:31
We shared ideas on how the surface condition, which we would slide these objects across, 00:02:35
might affect the friction force of each object. 00:02:40
We hypothesized about the effect the surface change would have on the objects. 00:02:44
Here are our test procedures we followed. 00:02:48
One metric ruler we identified as the test base and labeled with the number one. 00:02:52
It would be used to measure the length. 00:02:56
A second ruler labeled with the two was held upright for the test. 00:02:58
We would measure the height from this ruler. 00:03:03
The third ruler labeled with three was plastic and would represent the runway. 00:03:06
One person handled the runway ruler, one person held the height ruler, a third person was 00:03:10
responsible for reading the height and base measurements, and the fourth person was responsible 00:03:15
for recording data. 00:03:21
Running our two surface tests, we were interested in collecting the height measurement for the 00:03:23
vertical ruler and the length measurement from the base ruler at the point when an object 00:03:28
began to slide down the runway ruler. 00:03:34
We tested each object three times on both a smooth and rough surface. 00:03:37
The smooth surface was the back side of our plastic ruler. 00:03:43
The rough surface was the sandpaper attached to the ruler. 00:03:47
Here is a diagram to show you how the experiment worked. 00:03:51
Each test object was placed at the end of a ruler and then one end of the ruler was 00:03:55
slowly raised. 00:04:00
We stopped raising the ruler when the object started to slide down the slope of the runway 00:04:02
and then took our measurements of height and length. 00:04:07
Now that we have finished our testing, we are ready to look closely at our data. 00:04:10
First we will calculate the height and length average for each object on each of the surface 00:04:14
types. 00:04:20
Using these averages, we will apply Jones' formula to find the friction coefficient. 00:04:44
That formula is friction coefficient equals height divided by length. 00:05:05
Now we are ready to answer our question. 00:05:09
What effect does surface condition have on the friction coefficient between two surfaces? 00:05:12
Well, this is our experiment and we leave you with a challenge. 00:05:17
What other variables can you think of to test in this experiment? 00:05:22
Okay gang, you have received your challenge. 00:05:27
Complete your own runway traction experiment and then do further tests on different surface 00:05:30
conditions. 00:05:34
As we bring this program to a close, let me remind you to check out the CONNECT website 00:05:36
for responses from a variety of experts to questions posted throughout this program and 00:05:40
also to participate in an online friction experiment. 00:05:45
Let me slide things to Van now for some closing comments. 00:05:49
This is Shelly Canright for CONNECT, connecting you with real science and with real scientists 00:05:52
in near real time. 00:05:57
Take it away, Van. 00:05:59
Thanks Shelly. 00:06:01
I hope you all have a plain understanding of plain weather. 00:06:02
I know I sure do. 00:06:04
Join us for other CONNECT programs. 00:06:06
Simply access our CONNECT website for information and program availability. 00:06:08
So until next time, stay connected. 00:06:12
