Now we are going to draw a regular pentagon inscribed in a circumference,
00:00:00
and this is the most difficult exercise regarding polygons, okay?
00:00:04
So please pay attention, stop the video all the times you need it,
00:00:10
and make me questions in class if you have doubts, okay?
00:00:14
The first thing we are going to do is to draw a diameter, as we usually do, okay?
00:00:18
Okay, and now we are going to draw another one perpendicular to the previous one.
00:00:25
Okay, so I place here the square and down below I put the cartabon and I turn the square.
00:00:31
Okay, and I slide it till the center of the circumference.
00:00:41
Okay, I have two perpendicular diameters.
00:00:49
Yeah, I'm going to put names to the points so we can understand each other.
00:00:52
The center of the circumference is going to be O and this is going to be A.
00:00:56
And also it's going to be the first vertex of my pentagon.
00:01:01
OK, this is going to be B. It's not going to be part of my pentagon.
00:01:05
This is going to be C and this is going to be D.
00:01:09
OK, C and D are not parts of my of my pentagon either.
00:01:12
okay now I'm going to find the middle point of the radius OD okay so what I
00:01:17
have to do is to we are going to draw kind of a sector line okay so I'm going
00:01:24
to place the compass in D okay and with the same radius just the radius OD
00:01:32
I'm going to make an arch that cuts the circumference okay so then I'm going to
00:01:37
join these two points okay where the art cuts the circumference okay those points
00:01:45
are not important for anything well just for this for the sector line that we are
00:01:54
drawing but this point is not part of the circumference not neither this one
00:01:58
okay and here we have the middle point M okay the distance OM is supposed to be
00:02:03
the same that OD, okay? Let's check it. Let's check it with the compass, okay? DM, oops,
00:02:10
here, DM, okay? It must be the same, okay? Okay, MO. This exercise, as I have said, is
00:02:20
the most difficult because there are a lot of steps, okay? If you make mistakes in one
00:02:35
mistake you will have more mistakes over and over okay so now what we are going
00:02:40
to do is to place the middle of the compass in M and using the radius MA
00:02:47
okay the pencil in A we are going to make another arch okay cutting this part
00:02:53
of the diameter okay this radius and this point is going to be called N okay
00:03:02
n is not in the middle of this radius anymore okay here there is a golden
00:03:09
proportion okay or golden ratio but this we will talk about that in further years
00:03:14
okay and the most important thing that you need to know is that a n okay a n is
00:03:21
the misser of the side of the pentagon, okay? AN is the side of the pentagon, okay?
00:03:30
The polygon of five sides. So what we are going to do is to take this misser, that's
00:03:39
why it's important to have a very good compass, okay? And placing the needle in A,
00:03:45
we are going to make an arch okay that cuts this circumference four times okay
00:03:55
first time second time okay this is going to be number two and this is going
00:04:04
to be number five okay the vertex of my pentagon now I'm going to place the
00:04:16
compass in two okay making the point number three three okay and I'm going to
00:04:23
place my compass in five okay always is the same measure okay a and yeah do you
00:04:34
see the same measure and we put it here okay this is point four and just check
00:04:45
it okay the same measure must be here okay between four and three oh yeah must be the same measure
00:04:56
okay the distance between the five points is the same we have divided the circumference in five
00:05:05
equal parts now we are going to draw joining in each point each point each vertex we will have
00:05:13
our regular pentagon that is so so beautiful and so so perfect
00:05:23
