DIODO LED - Contenido educativo

Ajuste de pantalla

El ajuste de pantalla se aprecia al ver el vídeo en pantalla completa. Elige la presentación que más te guste:

Subido el 15 de octubre de 2018 por Isabel L.

70 visualizaciones

Más información Transcripción

Descargar la transcripción

Although we have already studied some electronic devices and some electronic elements, there are the inputs, such as, for example, potentiometer and so on. 00:00:02
We just only have two outputs which are diode and servo motor. The diode is like a bulb, it emits light, but just only when you connect correctly. 00:00:23
Otherwise, it doesn't work. 00:00:49
So, we are going to study the diode. 00:01:02
Firstly, we are going to study the semiconductor materials and in my explanation you can understand 00:01:06
what is a extrinsic semiconductor, what is a diode, its characteristics and its work point. 00:01:33
We are going to talk about some types of diodes and the application of the others. 00:01:45
Well, what is an intrinsic semiconductor? 00:01:53
Semiconductors are material or substance that they are in the nature and they can be conductor 00:02:04
insulators depending on the circumstances. One example of this kind of 00:02:17
substances could be silicon. Silicon has four electrons in the atom 00:02:28
constitution. So to link with other silicon atoms it usually share one 00:02:43
electron with each silicon neighbor as you can see in this picture. So if you 00:02:55
heat or if there is a very energetic life or other kind of energy, it is possible that 00:03:06
one of these links can be broken by energy. 00:03:18
So some electrons are free now and they can move the same way as electrons move in metals. 00:03:27
So it's a conductor substance. 00:03:45
Apart from this, the positive charges is created by holes in the net of silicon. 00:03:50
So not also the electrons can move, but holes can move also. 00:04:02
So there are two types of conduction in this material now. 00:04:16
One by negative churches, electrons, and another one by holes or positive churches. 00:04:24
This can be also explained using the band theory. 00:04:37
In the band theory, the semiconductors are systems with a gap between the conductor band 00:04:45
and the, between balance bands and conduction bands, there is a very small gap. 00:04:53
So it's very easy that the electrons can jump from the balance band to conduction band. 00:05:04
then the material is a conductor material and as as the way as the same way is conductor because 00:05:14
there are holes there are positive churches and there are also negative churches both of them can 00:05:23
move in the in the silicon net but we can we can do this by by replacing a 00:05:31
atom of silicon in the net of silicon by replacing this atom for example if you 00:05:46
replace an silicon atom with a boron atom, boron has one electron less, so it 00:05:57
creates, each boron atom can create a hole in the silicon net and this 00:06:12
substance is a conductor system because the holes can move in the 00:06:20
in the net. On the other hand if you put an atom which has more electrons than 00:06:30
for example an antimonium-1, electrons can move in the net and this is a 00:06:44
semi extrinsic semiconductor type N. Here could be what happens if I have one 00:06:53
part with a p semiconductor and another one with n semiconductors obviously they 00:07:10
tend to return to a combine and eliminate the holes and electrical extra 00:07:26
So there is a current, there is an intrinsic current in this type of device, which is usually called diode. This is a diode loop. 00:07:36
And if you put an external current, obviously, if you connect in the same way, this current can be strengthened. 00:07:52
On the other hand, if you want a current in opposite direction, that only can be possible 00:08:12
if you are if your current is bigger than the intrinsical current and this effect can be drawn 00:08:37
and it's the what's usually called characteristic of a diode the shape of the characteristic is 00:08:47
well it's the same for all of the diodes but the values of this depends on the 00:08:57
type of of the diode depends how many holes and how many electrons it has so 00:09:06
it's a difference however there's always a more or less a saturated zone which is 00:09:19
more or less 0.3 to germanium or 0.37 to silicon which is the 00:09:32
the maximum volta, the saturator of volta. I built a circuit in which there is a diode, 00:09:46
as you can see in this slide. Firstly, you need, obviously, resistance and using the Ohm's law, 00:10:03
So it's very easy to know or to have a relationship between the voltage in the diode and its current. 00:10:17
So you can draw this relationship in the characteristic cube and there is a point which is a junction between two mathematical functions. 00:10:32
This point is usually called working point and it shows the best conditions in which this diode can work. It's current and it's voltage. 00:10:54
and is a characteristic and it's very important to design a circuit with diodes. 00:11:13
There are various types of diodes, obviously, but this is the symbol of a normal diode 00:11:21
and you should connect the positive with the positive and the negative with the negative. 00:11:34
But we can also have lead, which emits light, which is bright. And another which is important also is zener, which you can use connecting with inverse polarity. 00:11:41
The normal diode is usually used in electronics to do rectificators, for example, or it is 00:12:03
also used to show if it has a current, or nowadays it is also used to give light because 00:12:16
is very very cheap and is very environmental friendly uh and so on to do a circuit using a 00:12:29
diode LED you should use 220 ohms resistance and it's really easy to do 00:12:45
that and obviously you you should do in a protoboard we will use diode with the 00:13:02
Arduino board so we will study better 00:13:15
this kind of circuits. It is all for today 00:13:20
