We are going to see some testing that you can do with Arduino board to improve your knowledge about robotics and to improve your experience with control board.
00:00:02
We have already described Arduino Bloor, so in this case we are going to study how to use Arduino Bloor.
00:00:28
We are going to use BitBlock2. BitBlock2 is an online application that helps you to program your Arduino Bloor.
00:00:40
and it's very easy to use because it's very similar to Scratch so firstly you should go
00:00:57
to the bitblog.bq.com address and then you can see this screen if you haven't if you have has
00:01:05
haven't if you don't have any account the first thing that you should do is
00:01:20
register in in this application with your username and password you can come
00:01:31
the application this is the first screen so you can click in new project a name
00:01:43
to new project in this case is pin 13 and we are going to do the first
00:01:56
experience which consists in a LED that is switching on and switching off
00:02:09
It's very simple because if you use the digital pin 13 of your Arduino board, you don't need any resistance.
00:02:20
So it's easier than you just only have to do. Connect the LED to the pin, to the correct pin.
00:02:43
So be careful when you connect the pins.
00:02:56
But in BitBlock application the next step is choose the Arduino board and then in this Arduino board let in the pin 13
00:03:03
after that go to the software and right now which is just only switch on wait for this time switch
00:03:26
off and wait again. It's a loop so the LED will be lightened and switch it off forever until you
00:03:43
disconnect the board. This is the board, this is the LED. Be very careful that the largest
00:04:08
bar is in the pin 13 and the smaller one is in the ground connection.
00:04:20
The connection, we are taking this in consideration, just only the led in the pin 13.
00:04:36
So if you download, compile and download the program and download to your board, the result
00:04:55
is like this it's very easy and well yes that is it's very easy as you can see but that is
00:05:13
the way that you have set to the computer that the pin has to work so be careful with when you
00:05:31
connect another in the left in another pin because in this case you should connect lead with a
00:05:57
resistance with a 220 resistance in this case we will have connect the lead to pin 7 so very
00:06:08
careful with the connection and very careful with in your layer that the
00:06:23
polarity is is well connected after that you you have to repeat the process goes
00:06:29
to this block choose your Arduino board choose left and connect it in pin 7
00:06:40
after that write the program and the result in this case is this more or less
00:06:51
the same but now in your board in your protoboard because your circuit is in
00:07:03
your protoboard and finally the last one is the servo motor as you can see this is the
00:07:11
the series so in your servo motor continuous over motor there are three
00:07:41
cables one red which should connect it should be connected to five volts black
00:07:49
one which should be connected to a ground connection and finally white one
00:07:59
which is control and this is the pin that you should connect in a digital
00:08:07
PIL 7 for example and also in your block you should choose the Arduino
00:08:14
board and as components the continuous servo motor and connect the
00:08:26
continuous motor in pin number seven is very easy because it's very similar to
00:08:36
the letter to the program that you have already written to the left but in this
00:08:47
case is without your servo it can be rotated to in time or anti times and
00:08:52
sense and waiting just only 200 milliseconds the result you can see the
00:09:06
result in this slide and it is the medium now you should do this is the
00:09:18
experiences and after that, the report of them.
