NASA Connect Segment involving students in an activity to create a wind tunnel to test the effect of drag while emphasizing data analysis.
Welcome to the Making Math Count Enrichment Camp at Saunders Middle School in Prince William County, Virginia.
00:00:00
NASA Connect asked us to show you how to make and build your own wind tunnel and use it to test certain shapes for drag.
00:00:09
Drag is one of the four forces that aeronautic engineers consider when they design airplanes.
00:00:15
The other three forces are lift, weight, and thrust.
00:00:20
Under the guidance of our teachers, Mr. Bill White, Ms. Melinda Spencer, and Ms. Trendyl Miller,
00:00:23
you'll look through the steps you'll use in constructing your wind tunnel.
00:00:28
Before you begin, go to this website to learn about wind tunnels.
00:00:31
This will give you a good understanding about the measurement tool you're about to build.
00:00:34
After you've gotten your materials together, we begin by measuring the fan.
00:00:38
Next, write the dimensions of the fan on the board.
00:00:42
Each student should fill out the data sheet by determining the dimensions for the eight trapezoid-shaped panels
00:00:45
of the upper and lower sections of the wind tunnel and the four smaller rectangular panels of the test chamber.
00:00:50
If the side of the fan is X, then the height and bottom width of the trapezoid shapes would be the same size
00:00:56
and the top would be one-third of X, or X over 3.
00:01:02
The dimensions of the test chamber panels would be X over 2 for the height and X over 3 for the top and bottom.
00:01:05
After checking the accuracy of the calculations, the teacher will divide the class into four teams.
00:01:12
Team 1, 2, and 3 will measure and mark their panels.
00:01:19
The teacher will then cut the panels.
00:01:22
The test chamber will fit between the upper and lower deflectors,
00:01:24
so it is very important that the measuring and cutting is accurate so the parts will fit together and be airtight.
00:01:27
Team 1 will cut a window in one of the panels and tape a piece of transparency film over it from inside.
00:01:33
Team 2 will cut a window in one of its panels and tape a piece of transparency film over it from the inside also.
00:01:38
Now carefully tape the sections together, making sure that the windows are on the same side.
00:01:45
When the wind tunnel is assembled, tape it to the box fan so then the air blows out of the bottom.
00:01:50
Place the wind tunnel and fan onto two chairs like this.
00:01:56
Make sure the chairs block as little airflow as possible.
00:02:00
To make the drag force test gauge, Team 4 cuts a 10 centimeter by 10 centimeter square card.
00:02:06
Next, punch a 1 millimeter hole 3 centimeters from the top center of the card.
00:02:13
Remove the elastic from inside the party hat and measure a 15 centimeter long piece.
00:02:19
Do not stretch the elastic when measuring.
00:02:26
Double it over to form a loop.
00:02:29
Thread the two loose ends through the hole in the card and tape them in place.
00:02:32
Next, mark the center of the card.
00:02:38
Beginning at the center point, draw a solid line to the right edge.
00:02:41
Using 2 millimeter interval, draw 5 lines above and below the center line that was just drawn.
00:02:46
Using card stock, cut in an equilateral triangle with each side 2 centimeters in length.
00:02:53
Cut two small slits in one side of the triangle and place the elastic through the slit
00:03:00
centering the measurement point of the triangle on the center line.
00:03:07
While Teams 1 and 4 are completing their assignments, use the templates to build the four polyhedrons,
00:03:13
tetrahedron, pyramid, cube, and cone.
00:03:19
Cut the shapes out, then bend along the dotted lines.
00:03:23
Carefully tape the edges together to form the shapes.
00:03:26
Tape string to the designated point on each shape.
00:03:29
When the shape is suspended in the wind tunnel, it should be visible in the center of the test chamber.
00:03:32
Now you are ready for testing.
00:03:37
Before turning on the fan, note the position of the gauge.
00:03:39
Start the fan on low speed.
00:03:43
Count how many lines the gauge moves.
00:03:45
Now increase the fan speed to medium.
00:03:47
Count how many lines the gauge moves from its rest position.
00:03:50
Do the same for high speed.
00:03:53
The number of lines the gauge moves indicates the drag force exerted by the wind on the object.
00:03:55
Run tests on the other polyhedrons.
00:04:01
Record your results on the student data sheet.
00:04:04
Now calculate the mean, median, and load for each polyhedron at each speed.
00:04:07
Using your results, make a graph.
00:04:12
This will help you compare the drag force of each of the shapes.
00:04:14
When all the data is collected and graphed, you are now ready to analyze the results.
00:04:18
Data analysis is one of the most important parts of an experiment.
00:04:23
You know, this would be a great time for you to stop the video,
00:04:27
use your thinker, and consider the following.
00:04:30
Which factor, shape, mass, wind speed, or drag is considered the constant?
00:04:33
That means which of those factors stays the same throughout the entire experiment.
00:04:40
And why is it important for this factor to remain constant?
00:04:45
Look at your data.
00:04:49
What relationship can you see between the shape of the object and the drag that's created?
00:04:51
More questions like these and their answers can be found in the Educator's Guide.
00:04:57
Teachers, you can download this from our NASA Connect website.
00:05:01
