Well, in this tutorial we are going to learn how to use Blockscat.
00:00:01
Blockscat is a very intuitive program which lets us design objects which can be printed.
00:00:09
Well, indeed, is the way that we should do this kind of designs, using blocks, using
00:00:24
commands and is the way that other programs such as OpenSCAD usually does this kind of
00:00:41
things. Well, we are going to use a blush cap to design a cup. If you see a cup you can
00:00:57
analyze it and think that it has a handle and the other piece that is more or less
00:01:17
a cylinder with a hole. So if you want to design this object
00:01:31
Obviously, you should begin with the main shape of this cup, which is the cylinder.
00:01:43
The BlocksCAD draws things using blocks, using commands, which is different from the other programs which have already been used.
00:02:01
So, if you go to the page which is blogscout.h10workshop.com
00:02:21
can register if you want to to keep your your draws and then have three areas
00:02:39
which are one in you can see the result of your program the commands which is on
00:02:52
the left and the work area so we are going to to create a cap firstly we
00:03:02
with a simple block with the 3d figures if you want to 3d figures you can see
00:03:19
that you can do some of them and for each figure you also have parameters in
00:03:29
this case the cylinder you have to radius and height so fix it to
00:03:41
radius to 40 millimeters and height to 90 you can see the result clicking on
00:03:53
renderize and it is the result well what I want now
00:04:08
I want to do a hole in order to get our cup so to do the hole we can use the
00:04:21
command difference, difference remove the second part to the first part so if we
00:04:35
do the difference between a cylinder of 40 millimeters remove a cylinder of 35
00:04:46
milliliters the result is what you want but the cap is not very good because we
00:05:00
we haven't a bottom piece so if you are clever enough to see this you can
00:05:13
translate the the second cylinder and then do the difference and the result is
00:05:24
is what you want, the cap.
00:05:33
So now we have the cap to create the handle,
00:05:36
but obviously to create the handle firstly,
00:05:49
you should enable what you have already drawn,
00:05:54
draw, because it's not clear
00:06:01
it's not very easy to see what you are doing so firstly enable the object
00:06:06
that you just already created and then we are starting with the handle
00:06:17
which is more or less the same but less high logically so you can do the same as you have
00:06:26
already done for the cup and if you do you will have a ring but it isn't
00:06:41
located well you should locate it the ring in the cup so to locate
00:06:57
you need firstly rotate the ring and then translate the ring and if you
00:07:12
rotate and translate the ring and and then you enable what you have already
00:07:24
the result is more or less what you can see here well and here I it's not the
00:07:34
same because I just made the first cylinder and put the handle. Well, if you
00:07:51
are a clever what you have to do now is to make the hole at the end so firstly you should join
00:08:11
the first cylinder which height is 90 and then make the hole and we have our hat our cup finished
00:08:29
and here it is the cap and finally you should download your work in
00:08:49
xtl format because if you want to print your work and that we have
00:09:04
study today I hope it could be it could be useful
00:09:24
