NASA Sci Files segment explaining how simple machines affect the effort necessary to perform tasks involving force.

Más información Transcripción

Descargar la transcripción

Hi guys. Hi Dr. D. What have you been doing? Just went for a bike ride to get a 00:00:00
little exercise. How's your project coming? We're excited about using pulleys 00:00:04
to lift Jacob into the treehouse, but we ended up with a lot of excess rope. Are 00:00:08
we doing something wrong? I figured you'd have some questions about pulleys, so I 00:00:12
set up a model over here. Let's try it out. 00:00:17
I have four kilograms or about nine pounds attached to this pulley system. Go 00:00:23
ahead and pull on the string. That's really easy. Why don't you lift the weight, 00:00:28
which we call the load one meter. We'll call this the load distance. 00:00:35
Wait a minute, Anthony. Where did all this string come from? I don't know. What's 00:00:41
wrong? Nothing's wrong. Let me explain. Simple machines allow you to multiply 00:00:58
your force. In this case, you can lift an object eight times as heavy as your 00:01:03
force. Right. We learned from the Cyphos Kids Club that you count the number of 00:01:07
strings supporting the load. I count eight strings, and that's why we can 00:01:11
multiply our force eight times. Very good, but there is a trade-off. What do you 00:01:17
mean? Remember that work is equal to force times distance. Okay. With simple 00:01:21
machines like pulleys, you can multiply your force, but not the work. So in this 00:01:28
case, you've multiplied your force eight times, but how much string did you have 00:01:33
to pull in? We'll call this your distance. 00:01:37
Eight meters. That means our distance is eight times the load distance. Does it 00:01:46
always work that way? Yes, it does. If you multiply your force, the trade-off is that 00:01:51
your distance will always be greater than the load distance. Take a lever, for 00:01:57
example. 00:02:02
Why don't I stand over here, and have you try to lift me up by pushing over there. 00:02:11
Try it with just one hand. Okay. 00:02:17
I can't believe I just did that. That was easy. Well, if your force is five 00:02:22
times further from the fulcrum, or rotational point, than the load, you will 00:02:33
multiply your force by five times. But your distance, how far you push down, will 00:02:38
also be five times greater than the load distance, how far I move up. 00:02:43
This is really cool. So if simple machines don't allow us to do less work, 00:02:51
or need less energy, why do we use them? I guess it's because they make the work 00:02:58
easier. Excellent. We still need to make our work easier. Right now, we've 00:03:03
multiplied our force three times by using three pulleys, but that isn't 00:03:07
enough to easily lift the load of 120 pounds. But if we add more pulleys to 00:03:10
multiply the force even more, that means that we have to pull in a lot more rope. 00:03:15
Wow. Maybe we need to use a different kind of simple machine. Don't scrap your 00:03:18
pulley idea. You might want to consider combining other simple machines with 00:03:22
your pulley system. You mean like use a lever with our pulley system? That's a 00:03:26
possibility. Another one is a wheel and axle. Take my bike, for example. This could 00:03:30
also be called a crank and axle. This wheel with the chain attached is the 00:03:37
axle. It's attached to this crank with the pedal. To find out how this machine 00:03:41
multiplies the force, all we have to do is divide the radius of the crank by the 00:03:46
radius of the axle. R.D., would you make the measurements, please? 00:03:51
The crank is 16 centimeters and the axle is 8 centimeters, so that means the 00:03:56
machine multiplies the force by two. That's great. Another possibility you may 00:04:08
want to explore is gears. I'm going to visit my grandparents in San Diego. We're 00:04:15
planning on going to Legoland. I bet there are a lot of gears in Legoland. 00:04:19
I'll send them an email and see if I can speak with someone about gears. Great. 00:04:22
Bye, Dr. D. Thanks. 00:04:26
