NASA Connect Segment explaining optics and the use of algebra in optics. Describes focal length, reflector telescope, and mirrors.

Más información Transcripción

Descargar la transcripción

What is optics, and how is algebra used in optics? 00:00:00
Optics is the study of light, what it is, how it moves through space, and how it interacts 00:00:07
with objects. 00:00:13
Light can be controlled with lenses and mirrors, and these elements can be combined into optical 00:00:14
instruments like telescopes, lasers, and cameras, just like the one being used to take this 00:00:19
picture now. 00:00:25
There are two types of telescopes. 00:00:26
This is a refractor telescope that has a lens in the front. 00:00:28
This is a reflector telescope that has no lens, but a mirror in the bottom of it. 00:00:32
The light from the object goes through the tube, is concentrated by the mirror, to form 00:00:37
an image which I see with my eye. 00:00:42
Reflector telescopes are better for looking at faint objects like distant stars, and are 00:00:45
therefore better for astronomy. 00:00:49
I've taken this mirror out of a telescope to show you how the light is focused down 00:00:51
to a spot at the focal point. 00:00:56
This distance from the spot to the mirror is called the focal length, and there's an 00:00:59
algebraic expression that relates the distance of the focal length, the distance u, to an 00:01:04
object, and the distance v to the image formed by the mirror. 00:01:10
That expression is 1 over f is equal to 1 over v plus 1 over u. 00:01:15
We use this equation to test telescopes here at the X-ray Calibration Facility. 00:01:19
We want to have the object source as far away from the telescope as possible, so we 00:01:24
put it at the end of this tunnel, which is a third of a mile, or 500 meters away. 00:01:28
Then, with the telescope at the other end, we measure the image formed by the mirror 00:01:33
very precisely, to make sure that the telescope is built properly, and will focus the stars 00:01:37
correctly. 00:01:42
And that's how we use algebra in optics. 00:01:43
Ground-based telescopes have revealed much over their nearly 400-year history, but they're 00:01:47
really limited in what they can show us. 00:01:53
Things like light pollution, cloud cover, and the Earth's turbulent atmosphere interfere 00:01:56
with ground-based telescope observations. 00:02:01
So in 1990, NASA launched the Hubble Space Telescope, an automated reflecting telescope 00:02:04
which orbits the Earth every 97 minutes. 00:02:10
The Hubble Telescope was named after Edwin Hubble, who discovered that the universe is 00:02:13
expanding, and the more distant a galaxy, the faster it appears to move away. 00:02:17
Remember the graph we analyzed at the beginning of the show? 00:02:22
Well, Hubble created a graph that's not too different from our pizza graph. 00:02:25
Check it out. 00:02:29
Hubble's graph shows a linear relationship between distance and velocity. 00:02:31
Remember the linear equation we used for the pizza graph, n times 2 equals p? 00:02:36
Well, the linear equation for Hubble's graph is h times d equals v. h is the Hubble constant. 00:02:41
It is similar to the number 2 in our previous equation. 00:02:48
Remember there were two servings and one pizza? 00:02:52
Anyway, d is the distance of the object, and v is the velocity, or speed, of the object. 00:02:54
