NASA Connect video containing five segments as described below. NASA Connect Video that explains how meteorology, specifically icing, effects the ground operations of aircraft. Explores research being conducted to study the effects of icing by using refri

Más información Transcripción

Descargar la transcripción

NASA's Aeronautic Safety Program is a program designed to help pilots fly their planes safer. 00:00:00
To know where storms are so they can fly around it. 00:00:11
To be sure they know where other planes are so they won't crash with them. 00:00:14
To understand where the ground is so they won't have difficult emergency landings. 00:00:18
It will help them maintain the planes better so they won't have engine problems, 00:00:24
they won't have cracks in the wings, they won't have electronics that fail. 00:00:29
It will help them see through storms and see through the night and it will make airports much safer. 00:00:33
Music 00:00:40
Hi, I'm Van Hughes for Connect. 00:00:56
You know it seems everybody is always talking about the weather. 00:00:59
I mean anyone can easily adapt to the change in weather conditions. 00:01:03
There are many variables that help define weather like the sun, the rain, and even the snow. 00:01:06
But weather can also influence a lot of things in our everyday life. 00:01:22
In this program you will learn how weather impacts air transportation 00:01:26
and the actions taken by pilots and ground operators in preparation for planes to fly during inclement weather conditions. 00:01:29
You will see two examples of NASA and FAA research that is currently being conducted 00:01:35
to address weather related air travel concerns. 00:01:39
For example, the F-106 behind me was subjected to lightning strikes by NASA researchers 00:01:42
to study how lightning impacts airborne aircraft. 00:01:48
That's pretty cool. 00:01:50
In this program you will be asked to participate in a math based problem 00:01:52
and experience first hand a demonstration of how weather can impact air travel. 00:01:56
At any time during this program when you hear this 00:02:00
and you see that on the screen, write down the Connect web address. 00:02:04
By using an internet accessible computer you'll be able to access NASA and FAA researchers 00:02:08
and hear from them their perspectives to questions presented throughout this program. 00:02:13
You'll also find other experts highlighted including meteorologists, pilots, and even kids like us. 00:02:17
But for right now, join us as we begin a new season of Connect. 00:02:23
Music 00:02:27
The United States is subjected to some of the world's most diversified weather conditions. 00:02:54
During the course of a normal year, our country may experience plus 100 degrees temperatures, 00:02:58
jungle humidity, negative 30 degrees cold, severe drought conditions, 00:03:03
as well as being the world leader in tornado activity. 00:03:07
Not to mention an occasional east coast hurricane. 00:03:10
As our transportation system has expanded, so too has our tendency to commute on a daily basis, 00:03:13
to work and recreational events. 00:03:18
The potential for weather to complicate our lives is therefore also increased. 00:03:20
Aviation, perhaps more than other readily available modes of transportation today, 00:03:24
is strongly impacted by weather conditions. 00:03:28
Did you know that 75% of all airport delays are related to weather? 00:03:31
In 1996, the estimated price tag for weather related delays, diversions, cancellations, 00:03:36
and unexpected operating costs was $2.1 billion. 00:03:41
The U.S. government invested approximately $830 million in aviation weather efforts during 1997. 00:03:45
As the magnitude of these numbers indicate, ensuring weather related safety and efficiency of flight 00:03:52
has economic and human life ramifications to business and traveling public communities. 00:03:57
Weather has a continual impact on both the safety of aircraft in flight 00:04:02
and the efficiency of operations throughout the national airspace system. 00:04:06
To complicate things even more, air traffic is projected to triple over the next 20 years. 00:04:10
More planes and people in the air fly longer distances more often. 00:04:15
Imagine what a weather delay will mean with more air traffic. 00:04:19
Talk about a traffic jam. 00:04:22
How important is weather information to your daily activities? 00:04:24
How well do you understand the weather system and the interaction of the various elements on the daily forecast? 00:04:27
But most of all, how might weather in one location affect your planned travel to a different region? 00:04:32
Today's meteorologists have the tools and advanced technology 00:04:39
to explain complex weather phenomena in a way that's simple to understand, 00:04:42
thanks largely to satellite information and computer-based modeling. 00:04:46
Dennis Smith of the Weather Channel in Atlanta, Georgia, 00:04:50
has offered to explain and help us understand the fundamentals of weather. 00:04:52
Dennis? 00:04:56
Thanks, Van. 00:04:58
As many of you know, the Weather Channel provides 24-hour weather information 00:04:59
both from a national and international perspective. 00:05:02
Our meteorologists constantly monitor and update weather information. 00:05:05
Now today, we're going to fly through some basic weather concepts 00:05:09
and talk a little bit about winter weather, which can cause some problems for aircraft. 00:05:13
To explain how our weather occurs, we must first travel out past the boundaries of our atmosphere, 00:05:20
93 million miles away. 00:05:25
Our sun emits visible and invisible energy that we call solar radiation. 00:05:29
Radiation from the sun travels through the Earth's atmosphere, 00:05:35
heating the air, the land, and the water it contacts. 00:05:38
The Earth's surface absorbs much more radiation than the atmosphere. 00:05:42
This means that the sun heats the ground, and the ground heats the atmosphere. 00:05:46
Not all parts of the Earth are warmed equally. 00:05:51
Regions around the equator receive more concentrated solar radiation 00:05:54
than do areas around the poles. 00:05:58
This means that the equator is warmer than the poles. 00:06:01
Temperature differences also result because land and water do not absorb solar radiation equally. 00:06:05
Because air moves, warm air and cold air are constantly mixing in the atmosphere. 00:06:12
This mixing not only evens out the global temperature contrast, 00:06:17
but results in the various weather conditions we see every day. 00:06:21
If solar radiation penetrates all layers of the atmosphere, 00:06:26
it is nearly all weather occur in the lowest layer, the troposphere. 00:06:30
The troposphere is warmest near the ground and cooler the higher you go. 00:06:34
This temperature pattern is favorable for the development of vertical air currents. 00:06:38
Relatively warm air tends to rise, and relatively cool air tends to sink. 00:06:42
As warm air rises in the atmosphere, it expands and cools. 00:06:48
As air cools, clouds can form, and precipitation can fall. 00:06:52
Warm air rising causes less pressure to be exerted by the atmosphere. 00:06:57
Lower air pressure. 00:07:01
Cool air falling causes more pressure to be exerted. 00:07:03
High air pressure. 00:07:06
As warm and cool air flow from one region to another, 00:07:08
pressure changes, and so can the weather. 00:07:11
When air pressure falls quickly, it usually means that stormy weather is approaching. 00:07:14
That's the result of a low-pressure system. 00:07:18
When air pressure rises, fair weather typically results. 00:07:21
That's the result of a high-pressure system. 00:07:25
Wind is another byproduct of changing air pressure. 00:07:28
Winds flow because of the pressure differences in the atmosphere. 00:07:31
Air moves from the areas of high pressure to areas of low pressure. 00:07:34
Winds spiral inward toward low pressure, causing a piling up of air, 00:07:39
forcing air to rise and cool, forming clouds and eventually precipitation. 00:07:43
Around high pressure, winds spiral outward, promoting sinking air and fair weather. 00:07:49
Okay, now, while you're soaking up that information, 00:07:55
let's think of something a little bit more fun. 00:07:58
Snow days. 00:08:00
When you think of winter, is this the picture you see? 00:08:03
Snow, snow, and more snow. 00:08:06
But there are other types of winter precipitation. 00:08:09
The type of precipitation that falls during winter depends on how warm air moves 00:08:12
over a layer of below-freezing air. 00:08:16
A good place to start is with sleet. 00:08:18
Sleet is frozen precipitation falling as ice pellets. 00:08:21
These ice pellets form when snowflakes pass through a thin layer of warm air and melt. 00:08:24
They refreeze into ice pellets as they fall through another layer of colder air close to the ground. 00:08:29
Freezing rain is made of water droplets that fall to the Earth's surface 00:08:35
and freeze upon contact with the ground or objects near the ground. 00:08:39
For freezing rain to develop, cold air close to the ground needs to be shallow. 00:08:43
The rain doesn't have time to freeze into ice pellets, 00:08:48
but upon contact with frozen objects, it turns into ice. 00:08:51
Snow is frozen precipitation in the form of a six-sided ice crystal. 00:08:56
Snow is produced in clouds where water vapor changes directly into ice crystals 00:09:00
that remain frozen as they fall to Earth. 00:09:05
Snow will fall when temperatures remain below freezing from the clouds to the ground 00:09:08
or when a very shallow layer of above-freezing air is present near the ground. 00:09:13
Winter weather can be a lot of fun to play in, 00:09:18
but it can cause some problems for us when we try to get out and travel, 00:09:20
either by foot, by car, and especially by air. 00:09:24
Now that you have a better understanding of weather, here's a question for you. 00:09:29
Weather reports of snow are typically based on visibility. 00:09:33
Snowfall is considered heavy when an observer cannot see very far through the flakes, 00:09:37
but visibility is not the critical element for the meteorologist interested in aircraft operations. 00:09:41
What do you suppose is the main issue that is considered 00:09:47
in looking at snowfall from the perspective of aviation? 00:09:49
Back to you, Van. 00:09:53
Thanks, Dennis. 00:09:56
We have just seen the weather channel for people, 00:09:57
but can you believe that airplanes need their own weather channel? 00:09:59
To tell us more about the aviation weather channel 00:10:02
is Tom Van Meter of the Federal Aviation Administration. 00:10:04
Thanks, Van. 00:10:10
Pilots need to have a continual awareness of the changing nature of the atmosphere on their route of flight 00:10:11
in order to be able to react to changing weather conditions in a safe, efficient, and timely manner. 00:10:15
It is the job of the weather coordinators here at the FAA's Air Traffic Control System Command Center 00:10:21
to provide aviation weather information to operational aviation decision makers, 00:10:25
such as traffic management and severe weather specialists here at the command center, 00:10:29
along with the traffic management units and severe weather specialists in the field facilities. 00:10:33
While the National Weather Service looks at a wide range of weather conditions, 00:10:38
the information that the weather coordinators are looking for is aviation-related, 00:10:41
such as icing conditions and thunderstorms, 00:10:45
that can have a major impact on the national airspace system. 00:10:47
Weather phenomena such as thunderstorms, clear air turbulence, volcanic ash, 00:10:51
and severe icing can cause large portions of the national airspace system to be unusable. 00:10:55
Geographical features and altitude also have an effect on aviation weather. 00:11:00
Moisture drawn from the Great Lakes can cause lake-effect snowstorms 00:11:04
to form on the east side of the Great Lakes, while the rest of the Midwest remains clear. 00:11:07
When icing conditions such as freezing rain occur at an airport, 00:11:12
ice may build up on aircraft wings, changing their shape 00:11:15
and adding a considerable amount of weight to the aircraft. 00:11:18
This change in shape and addition of weight can cause the aircraft to be unable to fly. 00:11:21
To counter the effects of icing at certain airports, the airport may go into a de-icing status. 00:11:26
De-icing is a slow procedure in which the entire aircraft is sprayed with a de-icing fluid 00:11:31
to remove the ice and temporarily prevent additional buildup. 00:11:35
Because of the time it takes to de-ice an aircraft, 00:11:39
there is a reduction in the number of aircraft that can depart from that airport. 00:11:41
When this happens, if a corresponding reduction in the arrival traffic is not made, 00:11:45
the number of aircraft on the airport will grow 00:11:50
until there is no longer any ramp space left in which to park additional aircraft. 00:11:52
This situation is known as gridlock. 00:11:56
The traffic management specialists at the command center 00:11:59
monitor the situation at airports in a de-icing status 00:12:01
and, if necessary, will adjust the arrival flows in order to accommodate the airport's capacity 00:12:04
and prevent it from going into gridlock. 00:12:09
When icing conditions aloft impact a large geographical area, 00:12:11
the traffic management specialists in the command center's severe weather unit 00:12:15
work with the affected facilities to develop routes around the icing conditions. 00:12:18
Aircraft that are not equipped for flight into icing conditions may use these routes 00:12:22
or may divert to another airport to wait until the icing conditions have passed. 00:12:26
Aircraft that are equipped for flight into icing conditions may fly through the area if desired. 00:12:30
Consider the weather-related condition of icing. 00:12:35
Are icing characteristics the same everywhere? 00:12:37
So let me ask you, how might geographic and atmospheric features 00:12:40
contribute to icing differences in different regions of the United States? 00:12:43
So now you know, people aren't the only ones that need a weather channel. 00:12:47
Consider the dilemma in working in the field of meteorology. 00:12:52
Unlike other science fields where laboratory tests can be performed under tight controls, 00:12:56
meteorology has no laboratory except for a vast dynamic atmosphere outside. 00:13:02
Our friends at the weather channel and the FAA Air Traffic Systems Command Center 00:13:07
have helped demonstrate the science and art in making weather predictions 00:13:12
and decisions that affect us on the ground and in the air. 00:13:16
Hi, I'm Shelley Canright, pre-college officer for NASA and host for the Connect series. 00:13:20
Thus far, we have been given some basic understanding of weather fundamentals 00:13:25
and the impact weather has on aviation operations. 00:13:29
Meteorological conditions, which have been frequent causes of aviation delays, 00:13:33
injuries and accidents include poor visibility, thunderstorms, wind chill or microbursts, 00:13:39
clear air turbulence, snow storms, freezing rain and icing. 00:13:44
In today's program, you will hear from leaders in the federal government 00:13:48
who have made aviation safety and aviation weather a specific mission. 00:13:52
Central to this is research. 00:13:57
It's a key factor in the development and implementation of new technologies 00:13:59
related to aviation weather. 00:14:03
And because of all that, you're going to have the opportunity to visit 00:14:05
some unique NASA facilities and witness groundbreaking research. 00:14:08
And as you listen to the researchers' stories on their investigations, 00:14:12
consider these questions. 00:14:16
What is the relationship between science and technology? 00:14:18
What is the role of mathematics and mathematical tools in scientific inquiry? 00:14:22
And what is the value of collaborations and partnerships in conducting research? 00:14:26
We have already mentioned the many types of meteorological conditions 00:14:32
that can affect aviation operations. 00:14:36
For the remaining portion of this program, though, 00:14:38
we're going to limit our focus on one type, icing. 00:14:40
Icing can have a profound effect on both the in-flight and ground operations of aircraft. 00:14:44
Let us visit two NASA research centers that are involved in various icing research studies. 00:14:49
We'll start our icing travels by visiting NASA Lewis Research Center in Cleveland, Ohio 00:14:54
and its Icing Research Tunnel. 00:14:59
Now, this facility is the world's largest refrigerated wind tunnel. 00:15:01
So bundle up. 00:15:06
Let's go visit this giant cooler and have a closer look at icing effects on aircraft 00:15:08
and the icing research being conducted. 00:15:12
Listen to learn how one measures the effects of ice on aircraft performance. 00:15:14
Thanks, Shelley. 00:15:21
My name is Dr. Judy Foss-Vanzanti, 00:15:22
and I'm standing in the test section of the Icing Research Tunnel. 00:15:24
Right now it's nice and warm in here, but later on it's going to get really cold. 00:15:27
All right. 00:15:31
What this tunnel was built for was to simulate down here on the ground 00:15:32
what it's like for an airplane to fly through an icing cloud up there. 00:15:36
We do this by creating a cloud that mimics what you see up there. 00:15:40
As one of the research engineers, I asked the operators to select five parameters. 00:15:45
One is the air speed coming past the model. 00:15:50
One is the temperature, how cold it is, always below freezing. 00:15:54
Two parameters are about the cloud density, how much water I have in the cloud, 00:15:57
and also how big each drop size is. 00:16:01
The final parameter I select is the time that I'll be flying through that cloud. 00:16:04
I select the cloud conditions. 00:16:08
I select the model. 00:16:10
I either select an engine, which provides the airplane forward thrust, 00:16:11
or I select a wing, which provides the plane lift. 00:16:15
And I want to see one of three things. 00:16:18
One is what kind of ice do I grow on my model? 00:16:21
What does it look like for the given cloud condition? 00:16:25
Another thing I might want to look at is how to keep ice from growing on that, 00:16:27
an ice protection system. 00:16:31
And a third thing I might want to look at is to see how well I can predict 00:16:33
what the ice shape is going to look like using a mathematical model and a computer. 00:16:36
All these three functions are done in the tunnel. 00:16:41
I used this tunnel along with Tom Ratvasky for the tailplane icing program. 00:16:44
What we did there was to see how ice contamination affects the operation of the tailplane. 00:16:48
Let's take a look at what the tailplane is and how it affects the aircraft operation. 00:16:54
What we have here is an animation of an airplane in flight. 00:17:00
The forces acting on this airplane are the weight, which acts through the center of gravity. 00:17:03
The upward lift is provided by the wing, 00:17:09
and the tailplane on the right side of the screen provides a downward lift. 00:17:12
In equilibrium flight, we've got the following force and moment balances to consider. 00:17:16
We've got the weight, which acts through the center of gravity, 00:17:21
which is also the aircraft's pivot point. 00:17:24
That's always forward of the wing's center of lift. 00:17:27
Those two forces acting together create a nose-down pitching moment. 00:17:30
The tail comes in to provide a downward lift. 00:17:34
As you can see, that's a simple geometry problem. 00:17:38
The plane acts an awful lot like a seesaw. 00:17:41
The tailplane icing project that Tom and I worked on investigated the question, 00:17:44
what happens if you move that wing's center of lift further back? 00:17:49
How does that affect the tailplane if you've got an ice shape on it? 00:17:52
We at NASA Lewis Research Center took this information and gave it to the pilots 00:17:56
so they can make better and safer operating decisions. 00:18:00
Back to you, Shelley. 00:18:03
Good science boils down to making as many high-quality observations as possible 00:18:05
and then analyzing and interpreting them. 00:18:11
At NASA Langley Research Center in Hampton, Virginia, 00:18:13
a five-year research program called the Joint Runway Friction Measurement Program is underway. 00:18:16
This international effort is investigating aircraft losing traction on icy runways. 00:18:22
This icing research program is having some groovy spinoffs. 00:18:28
Let's meet with Tom Yeager and learn more about Runaway Runways. 00:18:31
Thanks, Shelley. 00:18:36
I'm standing here this morning in our Aircraft Landing Dynamics Facility shop area. 00:18:38
Behind me you can see one of our test carriages. 00:18:42
We've got a display here of a landing gear system that we're looking at to evaluate 00:18:45
from a standpoint of reducing the loads going into the fuselage. 00:18:51
On my right here is a display showing some of the work that we've done 00:18:56
to support the Shuttle Tire Program that got started in the mid-'70s 00:19:00
and has been quite successful since then. 00:19:06
We've made several modifications to the runway down there 00:19:09
based on research data that we obtained here 00:19:12
at our Aircraft Landing Dynamics Facility in Hampton, Virginia. 00:19:15
We've also done work in modifying the tire design 00:19:19
and the brake unit that's used on the shuttle 00:19:23
that's being flown later on this month from Kennedy Space Center. 00:19:27
We do a lot of work looking at aircraft tread design, 00:19:34
how the grooves are positioned, and minimize the hydroplaning potential 00:19:37
that can occur during aircraft landing and takeoff operations on wet runways. 00:19:42
You're viewing a typical aircraft landing gear tire 00:19:48
touching down on a contaminated or ice-covered surface. 00:19:51
And due to the reduced friction capability between the tire and the ice, 00:19:56
it takes a considerably long time for this tire to spin up 00:20:01
to a speed that's equal to the forward motion of the airplane. 00:20:05
We're currently involved in the fourth year of a five-year program 00:20:10
with a partnership with the FAA, Transport Canada, 00:20:15
the National Research Council up in Ottawa, 00:20:19
the National Defense Department out of Winnipeg, 00:20:22
as well as several aviation organizations supporting this activity 00:20:26
where we're evaluating aircraft braking performance under winter conditions. 00:20:31
These conditions include snow, ice, slush, and water. 00:20:37
And to date, the majority of the tests have been taking place in North Bay, Ontario, 00:20:42
which is about two and a half hours north of Toronto. 00:20:48
We've evaluated braking performance of a Falcon 20, 00:20:52
a de Havilland Dash 8 airplane, an FAA Boeing 727 airplane, 00:20:58
and a NASA Boeing 737 airplane. 00:21:04
Coming up in this program, you'll be involved in a classroom experiment 00:21:08
that will give you a better idea of how the coefficient of friction 00:21:12
influences the motion of two objects, for example, pavements and tires. 00:21:16
In our work here at the track facility, 00:21:23
we've identified the fact that the higher the friction coefficient, 00:21:25
the shorter the stopping distance is for an airplane operating on a runway 00:21:29
and the less chance he has of going off either the side or the end of the runway. 00:21:33
Some of the equations that determine this behavior of vehicles operating on pavement surfaces 00:21:39
will be explained to you in the classroom experiment, 00:21:45
and I want to wish all of you good luck in conducting that experiment. 00:21:50
We've just seen the tip of the iceberg regarding the amazing research, 00:21:55
researchers, and research tools. 00:22:00
It makes me wonder, though, what other new technologies are under development 00:22:02
for reducing icing hazards. 00:22:05
But you know what? Now's the time to put you to work. 00:22:08
Coming up is a high school student who has spent the summer at NASA Langley 00:22:11
in a nine-week mentorship working closely with Tom Yeager. 00:22:15
John has prepared a special hands-on, minds-on activity, 00:22:18
which a group of students will demonstrate. 00:22:22
Following the program, you are encouraged to replicate the same investigation. 00:22:24
I spent nine weeks in a NASA program for high school students called SHARP. 00:22:30
Under this program, I had the opportunity to work with Mr. Yeager. 00:22:34
I learned a great deal about the research being done on runway friction, 00:22:38
tire designs, and new types of runway surfaces to minimize bad weather effects. 00:22:41
I have to admit I was a little nervous at the beginning 00:22:46
just because I wasn't sure if I knew enough math and science 00:22:48
to be able to grasp the research and to be able to help out 00:22:51
in the evaluation of the research data. 00:22:54
But I did okay. 00:22:57
I found that the math I had taken in middle school and high school 00:22:58
gave me a good foundation that I could build on. 00:23:00
With the help of two undergraduate students that I worked with during the summer, 00:23:03
Brian and Jonathan, I have a simple experiment that I would like you to try. 00:23:07
In this experiment, you will investigate how surface conditions influence 00:23:11
the coefficient of friction between two surfaces. 00:23:14
Your surfaces will include a ruler, sandpaper, and objects found in the classroom. 00:23:17
Now, my friends and I did an experiment similar to the one you're about to do, 00:23:21
but it was a little more complicated and involved a little more math. 00:23:25
This experiment has been recreated on the Connect to Plane Weather website, 00:23:28
so you might try this with your friends or your family following the program. 00:23:32
Enough said. Let's get started. 00:23:36
The math formula you will need in doing your experiment looks like this. 00:23:38
Friction coefficient equals height divided by length. 00:23:42
The following materials were collected for our experiment. 00:23:47
Three metric rulers, at least one of the rulers had to be plastic, 00:23:50
a sheet of sandpaper large enough to cover a ruler, 00:23:53
and four objects to test, a rubber eraser, a large metal paper clip, 00:23:56
a plastic film canister top, and a small dice. 00:24:01
John helped us identify the dependent and independent variables for our experiment. 00:24:04
The independent variable, which is what we would be changing, 00:24:08
is the ruler surface. 00:24:11
We used a plastic ruler to simulate a smooth runway surface, 00:24:13
and then a ruler covered with sandpaper to simulate a rough runway surface. 00:24:16
The dependent variable for the experiment was the classroom object. 00:24:20
Before doing our test, we talked about how each object was alike and different. 00:24:25
We shared ideas on how the surface condition, 00:24:30
which we would slide these objects across, 00:24:33
might affect the friction force of each object. 00:24:36
We hypothesized about the effect the surface change would have on the objects. 00:24:39
Here are our test procedures we followed. 00:24:44
One metric ruler we identified as the test base and labeled with the number one. 00:24:46
It would be used to measure the length. 00:24:51
A second ruler labeled with the two was held upright for the test. 00:24:53
We would measure the height from this ruler. 00:24:58
The third ruler labeled with three was plastic and would represent the runway. 00:25:01
One person handled the runway ruler. 00:25:05
One person held the height ruler. 00:25:07
A third person was responsible for reading the height and base measurements, 00:25:10
and the fourth person was responsible for recording data. 00:25:14
In running our two surface tests, 00:25:18
we were interested in collecting the height measurement for the vertical ruler 00:25:20
and the length measurement from the base ruler 00:25:25
at the point when an object began to slide down the runway ruler. 00:25:27
We tested each object three times on both a smooth and rough surface. 00:25:32
The smooth surface was the back side of our plastic ruler. 00:25:38
The rough surface was the sandpaper attached to the ruler. 00:25:42
Here is a diagram to show you how the experiment worked. 00:25:46
Each test object was placed at the end of a ruler, 00:25:50
and then one end of the ruler was slowly raised. 00:25:53
We stopped raising the ruler when the object started to slide down the slope of the runway 00:25:57
and then took our measurements of height and length. 00:26:02
Now that we have finished our testing, we are ready to look closely at our data. 00:26:05
First, we will calculate the height and length average for each object on each of the surface types. 00:26:09
Height 00:26:27
Length 00:26:30
Height 00:26:33
Length 00:26:36
Height 00:26:39
Length 00:26:42
Length 00:26:45
Height 00:26:48
Length 00:26:51
Using these averages, we will apply John's formula to find the friction coefficient. 00:26:54
That formula is friction coefficient equals height divided by length. 00:27:00
Now we are ready to answer our question. 00:27:04
What effect does surface condition have on the friction coefficient between two surfaces? 00:27:07
Well, this is our experiment, and we leave you with a challenge. 00:27:12
What other variables can you think of to test in this experiment? 00:27:17
Okay, gang, you've received your challenge. 00:27:22
Complete your own runway traction experiment and then do further tests on different surface conditions. 00:27:24
As we bring this program to a close, let me remind you to check out the CONNECT website 00:27:31
for responses from a variety of experts to questions posted throughout this program 00:27:35
and also to participate in an online friction experiment. 00:27:40
Let me slide things to the end now for some closing comments. 00:27:44
This is Shelly Canright for CONNECT, connecting you with real science and with real scientists in near real time. 00:27:47
Take it away, Van. 00:27:53
Thanks, Shelly. I hope you all have a plain understanding of plain weather. 00:27:55
I know I sure do. 00:27:59
Join us for other CONNECT programs. 00:28:01
Simply access our CONNECT website for information and program availability. 00:28:03
So until next time, stay connected. 00:28:07
♪♪♪ 00:28:10
♪♪♪ 00:28:40
♪♪♪ 00:29:10
Valoración:
  • 1
  • 2
  • 3
  • 4
  • 5
Eres el primero. Inicia sesión para valorar el vídeo.
Idioma/s:
en
Materias:
Matemáticas
Niveles educativos:
▼ Mostrar / ocultar niveles
      • Nivel Intermedio
Autor/es:
NASA LaRC Office of Education
Subido por:
EducaMadrid
Licencia:
Reconocimiento - No comercial - Sin obra derivada
Visualizaciones:
463
Fecha:
28 de mayo de 2007 - 16:52
Visibilidad:
Público
Enlace Relacionado:
NASAs center for distance learning
Duración:
29′ 21″
Relación de aspecto:
4:3 Hasta 2009 fue el estándar utilizado en la televisión PAL; muchas pantallas de ordenador y televisores usan este estándar, erróneamente llamado cuadrado, cuando en la realidad es rectangular o wide.
Resolución:
480x360 píxeles
Tamaño:
175.69 MBytes

Del mismo autor…

Ver más del mismo autor

EducaMadrid, Plataforma Educativa de la Comunidad de Madrid

Plataforma Educativa EducaMadrid
