Scaling the Solar System - Contenido educativo
Ajuste de pantallaEl ajuste de pantalla se aprecia al ver el vídeo en pantalla completa. Elige la presentación que más te guste:
NASA Connect segment that explores how astronomers and scientists use astronomical units in measuring distances in the Solar System.
Now that you have a better understanding of scaling,
00:00:00
let's turn our attention to the focus of today's program,
00:00:03
which is scaling the solar system.
00:00:06
Dr. Stan Odenwald, an astronomer and scientist
00:00:09
at NASA Goddard Space Flight Center, has a scoop.
00:00:11
Thanks, Jennifer.
00:00:17
When we talk about the distances between points of interest,
00:00:18
we instinctively use units that make sense to us
00:00:21
and that are convenient.
00:00:23
For example, what unit of measure would you use
00:00:25
to describe the distance from Washington, D.C.
00:00:27
to Los Angeles, California?
00:00:29
Would you use miles, inches, kilometers, or meters?
00:00:31
What about your height?
00:00:35
Would you measure it in inches or feet?
00:00:37
And how about the width of your classroom?
00:00:40
Do you use kilometers, meters, or feet?
00:00:42
You can choose any unit of measure you wish,
00:00:45
as long as it's convenient for everyone to understand.
00:00:48
When describing distances at the scale of the solar system,
00:00:51
even units like miles and kilometers
00:00:54
lead to numbers that are in the millions or the billions,
00:00:56
and that makes it very hard to understand them.
00:00:59
For example, the distance between the Earth and the Sun
00:01:01
is about 149 million kilometers.
00:01:04
Between the Sun and Pluto,
00:01:07
the distance is about 5.9 billion kilometers.
00:01:09
But suppose we wanted to compare these two numbers.
00:01:12
It's not easy to see that Pluto
00:01:15
is about 40 times as far from the Sun as Earth is.
00:01:17
It would make sense to use a smaller scale
00:01:21
in order to get a better idea of the distances between the planets.
00:01:24
To come up with that scale, we have to define a baseline.
00:01:27
The baseline that astronomers use
00:01:30
is the distance between the Earth and the Sun.
00:01:32
This distance is known as the astronomical unit.
00:01:34
The astronomical unit, or AU,
00:01:37
represents the distance between the Earth and the Sun,
00:01:40
which is about 93 million miles.
00:01:43
The astronomical unit is the baseline that astronomers use
00:01:45
to determine the distances to the planets in our solar system
00:01:48
and to the stars beyond.
00:01:51
So let's have a look at the scale of the solar system
00:01:53
where one astronomical unit equals 93 million miles.
00:01:56
Based on the astronomical unit,
00:01:59
it's easy to compare the distances
00:02:01
between all the other objects in the solar system.
00:02:03
The accompanying chart shows the distances to the planets from the Sun
00:02:06
in terms of astronomical units.
00:02:09
Let's look at Mars.
00:02:11
We can quickly see that Mars
00:02:13
is one and a half times further away from the Sun than Earth is.
00:02:15
So how far is Mars from the Sun in miles?
00:02:18
Remember the process Jennifer demonstrated earlier in the program
00:02:21
to solve problems involving scaling?
00:02:24
We can solve the Mars distance problem using a proportion.
00:02:27
The first ratio is the scale,
00:02:30
and the second ratio is the distance of Mars to the Sun.
00:02:32
N miles represents the distance from Mars to the Sun.
00:02:35
After setting these ratios equal to each other,
00:02:39
let's find the cross products.
00:02:42
The equation becomes 1 times N equals 93 million times 1.52.
00:02:44
Multiplying, we get the distance from Mars to the Sun
00:02:51
to be approximately 141 million miles.
00:02:54
Using the astronomical unit instead of the mile or the kilometer
00:02:57
makes it easier to compare the distances
00:03:01
between the planets and the Sun.
00:03:03
For example, it's easier to remember
00:03:05
that Mars is one and a half times further away from the Sun than the Earth
00:03:07
than it is to remember that it's 48 million miles
00:03:10
farther away from the Sun than the Earth.
00:03:13
If you recall from earlier in the program,
00:03:16
the Voyager spacecraft is 8 billion miles
00:03:19
or 13 billion kilometers from the Earth.
00:03:21
It's at the far edge of our solar system,
00:03:24
ready to head out into interstellar space.
00:03:26
Based on what you've learned about scaling and the astronomical unit,
00:03:29
can you estimate the distance of Voyager 1 from the Earth
00:03:32
in astronomical units?
00:03:35
Working with a partner, take a few minutes
00:03:37
and see if you can solve this problem.
00:03:39
Voyager 1 is over 8 billion miles away from Earth.
00:03:41
Estimate how far, in astronomical units,
00:03:44
Voyager 1 is from the Earth.
00:03:47
Remember the scale is 1 astronomical unit equals 93 million miles.
00:03:50
Teachers, you may now pause the program
00:03:55
so students can answer the problem.
00:03:57
Okay, so what did you come up with?
00:04:00
If you said that Voyager was 86 astronomical units away from the Earth,
00:04:02
you were correct.
00:04:06
Do you have a sense for how far that is?
00:04:07
The planet Pluto is 40 astronomical units away from the Earth.
00:04:10
So that means Voyager is twice as far away from the Earth as the planet Pluto.
00:04:13
Suppose that Voyager 1 were stationary
00:04:18
and you were able to ride in a car traveling at 55 miles per hour to get to it.
00:04:20
The trip would take you over 16,000 years just to reach the satellite.
00:04:25
That would be quite a lengthy and expensive vacation.
00:04:30
Jennifer, I think the students are ready for that hands-on activity now.
00:04:33
Could you send them back to me when you're finished?
00:04:36
I have a real tough question for them to answer.
