Electronic engineers require access to fast and efficient PCB prototyping. 00:00:07

To meet this need, we've developed a complete line for in-house PCB prototyping. 00:00:14

The heart of this line is the LPKF Protomats circuit board plotter. 00:00:19

The next generation of LPKF Protomats gets the job done more easily than ever before at industry production level. 00:00:23

When we were planning the new generation of Protomats, the following was clear. 00:00:30

project setup should become even faster and manufacturing should run 00:00:34

automatically. The user should have optimal support and guidance every step 00:00:38

of the way. The new Protomat generation draws on more than 30 years 00:00:43

of experience. The systems are now even more compact, faster and easier to use. 00:00:49

Our clients asked us to accelerate the tool change process and we did. The 00:00:56

The circuit board plotter adjusts the milling depth using a special ramp. 00:01:03

The tool is locked into position and the exact track width is created automatically and without 00:01:09

any intervention by the user. 00:01:14

Our clients told us that the camera is a real help in their daily work so we developed the 00:01:19

optical fiducial recognition even further. 00:01:23

The camera recognizes the fiducials with perfect accuracy and the software processes the information 00:01:26

And extremely quickly, everything fits together, even when carrying out complex tasks like 00:01:32

manufacturing multi-layers. 00:01:37

And what's really great is that everything can be upgraded. 00:01:42

The protomats grow according to the tasks at hand. 00:01:45

The entry-level model S43 can be easily upgraded with a do-it-yourself kit, even to the high-end 00:01:49

S103 model. 00:01:54

Another highlight is the new LPKF CircuitPro software, which handles data preparation and 00:02:00

machine control. The goal here, too, was to make a best practice even better. The focus 00:02:05

in the development of the software was on usability and the user interface. Everything 00:02:10

had to be intuitive. No unnecessary or confusing sub-menus. Wizards guide you reliably through 00:02:16

the production process. 00:02:22

And our thinking went even a step further. A new dispenser unit applies soldering paste 00:02:27

directly onto the board, a logical step for PCB prototyping, 00:02:32

milling, drilling, and applying solder paste. 00:02:37

No engineering lab should be without the LPKF protomat. 00:02:42

That's because the protomat enables independence 00:02:46

from outside suppliers and their schedules, 00:02:48

and that's a clear advantage. 00:02:51
