NASA Connect segment explaining the forces that affect the X-33 and how these forces relate to everyday objects. The video explores weight and aerodynamics and how to design vehicles to become more efficient.

Más información Transcripción

Descargar la transcripción

How can you improve the performance of a bicycle? 00:00:00
Explain two forces that affect both X-33s and a bike's performance, and could you tell 00:00:13
us how they relate to each other? 00:00:18
Okay, so we've collected the baseline information from Van's one-mile test run, and I think 00:00:20
we can all agree that some improvements need to be made. 00:00:25
Now, obviously, we can't change the size of the bike, but, I mean, can't we improve some 00:00:28
of the bike's technologies or something? 00:00:33
Yeah, make it lighter so it's easier to pedal, maybe. 00:00:35
Right. 00:00:38
You can decrease the force that will take the pedal by decreasing the weight of the 00:00:39
bike. 00:00:41
One way that you can do it is to replace the frame with one that is made of a new, lighter, 00:00:42
stronger composite material instead of this heavy steel. 00:00:47
That's something we have to do with the X-33. 00:00:51
We already learned from our subscale testing that both for the X-33 and the larger Venture 00:00:54
Star, we're going to need to use composite materials in order for both of them to reach 00:00:58
space. 00:01:02
You know, it seems to me that part of Van's struggle was the bike's poor aerodynamics. 00:01:03
That's another common challenge the X-33 and your bike share, moving through the air easily 00:01:09
and with less resistance. 00:01:13
A lot of this has to do with the geometry, so the shape of the vehicle is critical. 00:01:15
The X-33 has a wedge-shaped design. 00:01:19
I suggest you look for ways to make the bike more aerodynamic, otherwise you're just fighting 00:01:22
the force of drag. 00:01:27
Drag is simply the resistance of an object caused by the air, in this case, through which 00:01:29
it is moving. 00:01:33
Yeah. 00:01:34
Since X-33 is a flying machine, we also need to generate lift. 00:01:35
That's the force that supports objects as they move through the air. 00:01:38
Well, you can't test that with a test run like mine. 00:01:41
No, but we can simulate it on a computer, or we can run small-scale models in the wind 00:01:44
tunnel. 00:01:49
Oh. 00:01:50
So we can make the bike less resistant to air and gravity, but what else can we do? 00:01:52
One thing you can do is you can make the power source more efficient. 00:01:59
Now on the bike, you're the engine. 00:02:02
Are you sure you're using the gears correctly? 00:02:04
No, I don't even know how they work. 00:02:06
I normally just keep it in third. 00:02:08
Well, you know what? 00:02:09
Let me show you how they work. 00:02:10
It's really easy, and it'll make you a lot more efficient. 00:02:11
Well, Van, those gears are there for a reason. 00:02:14
See, when you are riding or racing bikes, you want to use your energy as efficiently 00:02:17
as possible. 00:02:22
To do this, you need to use your gears correctly. 00:02:23
They will help you pedal at the same rate throughout the race and help conserve your 00:02:26
energy. 00:02:30
For instance, when biking uphill, use a low gear, and when biking downhill or on a flat 00:02:31
road, use a higher gear. 00:02:36
Like the gears on your bike, the X-33 will also make the most efficient use of the environment 00:02:39
by using two revolutionary linear aerospike engines. 00:02:44
That's so cool. 00:02:47
Hey, let's head to Cookville, Tennessee. 00:02:49
There, we're going to meet some students who are making their own models of the X-33. 00:02:51
