Hi, I'm Neil Armstrong, commander of the Apollo 11 mission. 00:00:00
That's one small step for man, one giant leap for mankind. 00:00:20
I'm working with the American Institute of Aeronautics and Astronautics on the Evolution of Flight campaign. 00:00:28
This campaign marks the 100th anniversary of flight and lays the groundwork for the next 100 years of innovation in aviation and space technology. 00:00:35
AIAA and NASA Connect are excited to give you the opportunity to learn about the aircraft design process. 00:00:46
You'll see a really cool experimental aircraft. 00:00:55
You'll observe NASA engineers and researchers using math, science, and technology to solve their problems. 00:00:59
In your classroom, you'll test and improve wing designs. 00:01:06
In our instructional technology activity, you will become an employee of Plane Math Enterprises to design and test aircraft using a computer. 00:01:10
So stay tuned as host Dan Jerome takes you on another exciting episode of NASA Connect. 00:01:21
Hi, welcome to NASA Connect, the show that connects you to math, science, technology, and NASA. 00:01:51
I'm Dan Jerome, and today I'm at the National Air and Space Museum in Washington, D.C. 00:02:05
Over my shoulder is the Wright Flyer. 00:02:10
This is the first manned airplane to fly under its own power. 00:02:13
It was built by the Wright brothers. 00:02:16
This is the Bell X-1, the first plane to break the sound barrier. 00:02:18
Notice how sleek its shape is. 00:02:22
And this is the X-15. 00:02:24
It's the first airplane to fly into space. 00:02:26
Notice how closely shaped it is to a rocket. 00:02:29
There are tons of planes here. Let's take a look. 00:02:32
Now, before we continue our show, there are a few things you and your teacher need to know. 00:02:48
First, teachers, make sure you have the lesson guide for today's program. 00:03:10
It can be downloaded from our NASA Connect website. 00:03:14
In it, you'll find a great math-based hands-on activity 00:03:17
and a description of our instructional technology components. 00:03:20
Kids, you'll want to keep your eyes on Norbert, 00:03:24
because every time he appears with questions like this, 00:03:26
have your cue cards from the lesson guide and your brain ready to answer the questions he gives you. 00:03:29
Oh, and teachers, if you're watching a taped version of this program, 00:03:34
every time you see Norbert with a remote, 00:03:38
that's your cue to pause the videotape and discuss the cue card questions. 00:03:40
Today's show is about the future of flight. 00:03:44
But before we talk about the future, what is commercial flight like today? 00:03:46
And what current technologies are being used by pilots? 00:03:50
Hi, I'm Connie Tobias, and I'm a pilot with U.S. Airways. 00:03:56
This modern Airbus aircraft gives us the tools we need to navigate safely and efficiently 00:04:00
through today's complex air traffic control system. 00:04:05
The Airbus aircraft has an array of computer screens 00:04:09
that give the pilot information about performance, navigation, weather, 00:04:12
and the location of other aircraft in our airspace. 00:04:16
About 10 years from now, over 3 million people will be flying every day. 00:04:19
That's about 1 million more than today. 00:04:23
Updated computer technology and faster aircraft will be needed to deal with this increase 00:04:26
and to reduce the travel time between destinations. 00:04:31
Thanks, Connie. 00:04:38
Now that we know what pilots have to keep in their minds with today's aircraft, 00:04:39
let's consider the future of flight. 00:04:42
Have you ever wondered what the airplanes of tomorrow will look like? 00:04:45
Or how fast they will travel? 00:04:48
Will tomorrow's planes travel into space or beyond? 00:04:50
On today's show, we're going to learn how NASA researchers and engineers 00:04:53
are using geometry and algebra to design, develop, and test future experimental airplanes. 00:04:56
What is an experimental plane? 00:05:02
Experimental planes, or X-planes, are tools of exploration that come in many shapes and sizes. 00:05:06
They fly with jet engines, rocket engines, or with no engines at all. 00:05:11
Which means NASA flies not only the fastest airplanes, but the slowest as well. 00:05:15
Some planes are too small for a pilot, and some are as large as an airliner. 00:05:20
The research conducted on experimental aircraft today gives us a glimpse into the future. 00:05:24
NASA is developing one of the fastest experimental X-planes ever. 00:05:29
It's called the HyperX. 00:05:33
What is the HyperX? 00:05:35
The HyperX research vehicle is an experimental plane 00:05:37
that uses this really cool engine technology called the scramjet. 00:05:40
Go for main engine start. 00:05:44
Unlike rockets, such as the Space Shuttle main engines, which must carry both fuel and oxygen, 00:05:47
the scramjet will only carry hydrogen fuel. 00:05:52
It will take in oxygen out of the thin upper atmosphere as it travels along. 00:05:55
We call this kind of engine an air breather, and it will allow the HyperX to fly at incredible speeds. 00:05:59
In fact, the HyperX will fly at about 3,020 meters per second, 00:06:05
which is about 6,750 miles per hour, or Mach 10. 00:06:09
What does Mach number mean? 00:06:13
Mach number represents how many times the speed of sound a vehicle is traveling. 00:06:15
For example, Mach 1 equals the speed of sound, 00:06:19
which is approximately 302 meters per second, or 675 miles per hour, 00:06:23
at an altitude of 100,000 feet, which is the test altitude for the HyperX. 00:06:28
Mach 2, which is twice the speed of sound, 00:06:33
will approximately be 604 meters per second, or 1,350 miles per hour, 00:06:36
at an altitude of 100,000 feet. 00:06:41
Mach numbers are used by NASA researchers to describe the speed at which a plane is flying. 00:06:44
Let's use algebra to show how to calculate the Mach number of the HyperX, 00:06:49
which is flying at 3,020 meters per second, or 6,750 miles per hour. 00:06:53
This algebraic equation shows that the Mach number equals the speed of the plane 00:06:58
divided by the speed of the sound in the air, where M is the Mach number. 00:07:02
V is equal to the speed of the plane, and A is equal to the speed of sound in the air. 00:07:06
If the speed of the plane is 3,020 meters per second, 00:07:11
and the speed of sound at 100,000 feet is 302 meters per second, 00:07:14
then what is the Mach number? 00:07:18
That's right! 00:07:21
3,020 meters per second is about Mach 10, or 10 times the speed of sound. 00:07:23
We'll learn more about Mach numbers later in the show, 00:07:29
but first, let me tell you about the HyperX. 00:07:32
The HyperX is designed as a flying engine, 00:07:37
which means the airplane and the engine are one unit. 00:07:40
The unique shape of the airplane develops the lift necessary to keep the plane up in the air, 00:07:43
so it doesn't need wings to produce lift. 00:07:48
The entire undersurface of the airplane is designed to act as part of the engine. 00:07:50
In order to test the scramjet engine, the HyperX is launched by NASA's B-52 00:07:55
and boosted by a rocket to its testing altitude. 00:07:59
It will then separate from the rocket, and the scramjet engine will begin its test flight. 00:08:02
So, have you ever wondered what goes into designing an experimental plane, 00:08:10
such as the HyperX? I know I have. 00:08:14
I'm here at NASA Langley Research Center in Hampton, Virginia, to talk to Dr. Scott Hull. 00:08:17
What are the steps in designing an aircraft? 00:08:26
How do the mission requirements of an aircraft determine its shape? 00:08:29
Why are wind tunnels important in testing aircraft designs? Why? 00:08:33
Hi, Dan. 00:08:39
Hey. 00:08:40
HyperX is definitely a very exciting program. 00:08:41
In my job, I use wind tunnels to determine the flying characteristics of a variety of different vehicles 00:08:43
that fly many times faster than the speed of sound, like the HyperX. 00:08:48
The exciting part of the HyperX program is that it's truly pioneering. 00:08:51
That means no one's ever done it before, so we have to blaze the trail. 00:08:55
NASA sure has blazed many trails. How do they do it? 00:08:58
The first thing you have to do when blazing a trail is to determine a mission, or where you want to go. 00:09:01
We develop a set of requirements for the vehicle, 00:09:06
and then we begin a process of designing a vehicle to meet that mission. 00:09:09
Have you ever been to an air show to see a bunch of different airplanes? 00:09:12
Yeah. Some planes are short, some are long and slender, some fly slow, and some fly fast. 00:09:14
You're right. They look and perform differently because they were designed to satisfy different missions. 00:09:20
For the HyperX program, our mission is to have it fly very fast. 00:09:24
We also want to be able to control it, and we want it to be able to propel itself. 00:09:28
You see, NASA has many years of experience testing fundamental shapes 00:09:31
to understand and document how those shapes, we call them geometries, 00:09:35
respond to the airflow at various speeds. Let me show you. 00:09:39
The Apollo capsules used to bring the astronauts back to Earth after their trips to the moon 00:09:45
were designed as blunt bodies. 00:09:49
This is because this particular shape has high drag, a force that slows an object down. 00:09:51
The blunt body creates the drag needed to deploy the drogue parachute, 00:10:03
followed by the main parachutes. 00:10:08
The force of drag, then, gently lowers the vehicle safely to the Earth. 00:10:11
NASA had to design a vehicle that would slow down to speeds where it was safe 00:10:17
to deploy the parachute for landing in the ocean. 00:10:21
Okay, I get it. But what about other shapes? 00:10:23
Well, we know that slender shapes, like the Concorde, have less drag. 00:10:26
A vehicle that has to propel itself, like the Concorde or the HyperX, 00:10:30
has to have an engine with enough power to overcome the vehicle's drag. 00:10:34
So if you were designing the HyperX to propel itself and fly really fast, 00:10:37
would you want a blunt body or a slender body? 00:10:41
I'd want a slender body. 00:10:43
That's right. 00:10:45
The HyperX is designed as a slender body because it has less drag for the engine to overcome. 00:10:48
You're well on your way to becoming a conceptual designer, Dan. 00:10:53
I am? Sweet. 00:10:56
So, once you've decided on a mission, what's next? 00:10:58
Detailed design. 00:11:02
A conceptual designer makes decisions, like the one you just made, 00:11:04
to find a geometry that will meet the mission requirements. 00:11:07
A detailed designer uses tools such as CAD or computer-aided drafting to turn ideas into drawings. 00:11:10
These drawings help us work out the details of how to design parts of the HyperX, 00:11:16
like the engines, the control surfaces, the fuel tanks, and so forth. 00:11:20
Once we have an initial design, we begin a process to improve it. 00:11:23
We compare the design of the HyperX to other vehicles with similar characteristics. 00:11:26
We may need to make changes to the geometry to improve the performance. 00:11:30
How do you know if you need to change the shape? 00:11:34
One way is conducting wind tunnel tests. 00:11:36
You see, during the design and computer modeling stages, 00:11:39
we extensively used our wind tunnels to quickly screen our HyperX designs. 00:11:42
And then, the wind tunnel tests helped us to determine the best design 00:11:46
and to understand how the vehicle will fly. 00:11:49
Okay, so what is a wind tunnel? 00:11:52
Wind tunnels are devices that allow us to move air over a scale model of a flight vehicle, 00:11:55
like the HyperX. 00:11:59
We use models instead of the real vehicle because they're smaller, less expensive, 00:12:01
and easier to change if needed. 00:12:05
This is NASA Langley's 31-inch Mach 10 wind tunnel. 00:12:08
This tunnel can get the air moving up to 10 times the speed of sound. 00:12:11
Once we place the model of the HyperX in the wind tunnel, 00:12:14
we make measurements to determine how the air interacts with the model. 00:12:17
At the nose of the vehicle, the flow near the surface is very smooth. 00:12:20
We call it laminar. 00:12:23
But as the air moves down the length of the body, it changes and becomes turbulent. 00:12:25
You can see this natural process by looking at the smoke after you blow out a candle. 00:12:29
After you've blown out a candle, you'll notice that the smoke near the candle rises smoothly. 00:12:34
That's laminar flow. 00:12:38
But farther away from the candle, you'll notice it becomes rough and irregular. 00:12:40
That's turbulent flow. 00:12:43
Normally, we think of laminar flow when designing aerodynamic shapes. 00:12:45
We want the air to flow smoothly around them. 00:12:48
However, for the HyperX geometry, we require turbulent flow. 00:12:50
Why would you want turbulent flow on the HyperX? 00:12:53
In order for the scramjet engine to work properly. 00:12:56
You see, turbulent airflow enhances the mixing of the air with the hydrogen fuel for better engine performance. 00:12:59
Turbulent airflow is created by a device called a trip located underneath the belly of the HyperX. 00:13:05
Using the wind tunnel, we tested several trips with different shapes or geometries 00:13:10
to see which one worked best to change the airflow from laminar to turbulent. 00:13:14
Our wind tunnel tests determined that this triangular-shaped trip was the best design 00:13:18
for creating turbulent flow for the scramjet engine on this vehicle. 00:13:21
How do you test the scramjet engine? 00:13:24
We have specialized wind tunnels capable of testing scramjets, 00:13:26
but the ultimate proof of the HyperX is flight testing. 00:13:29
That's the last phase in designing an aircraft. 00:13:32
NASA conducts all of its flight tests on aircraft at the NASA Dryden Flight Research Center in Edwards, California. 00:13:35
Thanks, Scott. 00:13:41
We'll visit NASA Dryden Flight Research Center later in the show. 00:13:43
But first, join me in Dan's Domain, 00:13:46
where we'll use technology to prepare for today's math-based, hands-on activity. 00:13:49
Welcome to my domain. 00:13:57
In just a minute, we'll get to the hands-on activity, 00:13:59
which will require that you use different shapes in designing airplanes. 00:14:02
Before we do, let's take a look at Riverdeep Interactive Learning's destination math tutorial. 00:14:05
It's available free to NASA Connect educators. 00:14:10
You can get to it from the NASA Connect website. 00:14:13
It's part of the Mastering Skills and Concepts III section of Destination Math. 00:14:16
With this lesson, you will explore the geometric and algebraic characteristics of basic shapes. 00:14:20
Teachers, this is an excellent tutorial that can give your students information and assistance 00:14:26
as they prepare to do the hands-on activity for the show. 00:14:31
In this tutorial, Digit explores parallelograms, trapezoids, and right triangles 00:14:34
while examining the flags of some of the countries in the United Nations. 00:14:40
Many thanks to Riverdeep for providing NASA Connect 00:14:43
with this exciting instructional technology enhancement to our show. 00:14:46
Now, let's do an aircraft design activity which you can do in your classroom. 00:14:50
We're from Pulaski Middle School. 00:15:00
Here in New Britain, Connecticut. 00:15:02
NASA Connect has asked us to show you this show's hands-on activity. 00:15:04
Here are the main objectives. 00:15:08
You'll use algebra to calculate wing area and aspect ratio. 00:15:11
You'll use a portable glider catapult to analyze wing geometry. 00:15:15
You'll design, construct, and test an experimental wing. 00:15:19
And you'll work in teams to solve problems related to wing design. 00:15:22
The list of materials you'll need for this activity can be downloaded from the NASA Connect website. 00:15:26
The class will be divided into groups of four. 00:15:31
Each group will use a portable glider catapult, or PGC, which your teacher made previous to this activity. 00:15:33
Good morning, boys and girls. 00:15:38
This morning, NASA has designated this class as Aeronautical Engineers in Training. 00:15:40
Your job is to test current wing designs based on distance traveled, glide, and speed observations. 00:15:45
From your analysis of the data that you collect, 00:15:53
you will have the task of designing and testing an experimental wing to achieve maximum distance traveled. 00:15:56
First, cut out the templates for the fuselage, wings, and horizontal stabilizers. 00:16:05
Place the templates on the meat trays and trace around the templates. 00:16:09
Cut out the shapes. 00:16:12
Tip a piece of masking tape to the nose of the fuselage to prevent the nose of the fuselage from breaking. 00:16:14
Students will calculate the wing area, the wing span, the root chord, the tip chord, and the average chord for each wing. 00:16:20
The average chord can be calculated using this formula. 00:16:26
Next, have students calculate the aspect ratio for each wing using the formula wing span divided by average chord. 00:16:31
Record all values onto the data chart. 00:16:38
Prep the launch area by measuring 12 meters in the PGC. 00:16:41
Mark the distance at one meter intervals. 00:16:45
Place tables or desks of equal height to the launching line to elevate the portable glider catapult. 00:16:47
Place a book with a height of approximately 5 centimeters under the front portion of the PGC. 00:16:53
Select a wing shape to test. 00:16:58
You will be testing four different shapes. 00:17:00
Delta. 00:17:02
Oblique. 00:17:04
Straight. 00:17:06
And swept back. 00:17:08
Attach a small binder clip to the aircraft to give it some weight in order to achieve maximum distance traveled. 00:17:10
Position the aircraft on the PGC. 00:17:16
Using a rubber band, pull the aircraft to the launch position. 00:17:19
Then announce, 00:17:22
Clear the flight deck for aircraft catapult. 00:17:23
5, 4, 3, 2, 1, launch. 00:17:27
You will conduct five trials for each wing shape. 00:17:36
Measure the distance traveled in centimeters and record the value onto the data chart. 00:17:40
Record your observations on glide and speed ratings using the scales provided from the lesson guide. 00:17:45
From the data collected, each group will design and construct their own experimental wing. 00:17:51
Design your wing to fly farther than the original test wings. 00:17:55
Okay now, how successful or unsuccessful was your experimental design? 00:17:58
What were the factors? 00:18:03
Resume. 00:18:05
Mine had a lower aspect ratio. 00:18:06
Big work. 00:18:09
Mine had a better swept back wing. 00:18:10
Special thanks to the AIAA Connecticut section and the AIAA mentors who helped us with this activity. 00:18:12
Thanks. 00:18:21
We had a great experience today. 00:18:22
And we encourage teachers to visit our website to learn more about the AIAA mentorship program in your area. 00:18:24
Okay, we've learned how geometry is important in designing an experimental aircraft. 00:18:36
We've also learned some steps in the aircraft design process. 00:18:41
But there's still one more step to go. 00:18:44
Scott mentioned earlier that the last stage in designing an aircraft is flight testing. 00:18:46
Well, the lead center for flight testing is NASA Dryden Flight Research Center in Edwards, California. 00:18:51
Let's take a look and see what they're doing with the HyperX. 00:18:57
How will the HyperX reach its test altitude? 00:19:02
How do the HyperX engineers collect their research information? 00:19:05
Why is algebra important in HyperX research? 00:19:09
Hi, I'm Lori Marshall. 00:19:14
I'm a research engineer in the aerodynamics branch here at NASA's Dryden Flight Research Center. 00:19:16
I'm one of the engineers responsible for getting the HyperX ready for flight. 00:19:21
In order to do this, we perform tests on the vehicle to ensure that the instrumentation system will measure the necessary data. 00:19:26
We make sure that the control room is set up properly to record this data during flight. 00:19:34
We also perform inspections of the HyperX during assembly and testing to ensure that the systems are operational and that no damage has occurred. 00:19:39
You see, the HyperX is a thermal protection system, similar to the space shuttle. 00:19:47
The exterior is covered with special tiles that allow it to withstand the high temperatures of high-speed flight. 00:19:52
If any of the tiles were damaged, not only would the vehicle structure be compromised, 00:19:58
but the aerodynamic shape that we've tested during the design process could also be altered, and this could affect the flight. 00:20:03
How do they flight test the HyperX at such high speeds? 00:20:09
Great question! 00:20:13
The HyperX is a very small vehicle, about the size of two kayaks side-by-side. 00:20:15
As Scott told you earlier, it will fly at about Mach 10. 00:20:21
Now, because of its size, we only have enough fuel for use at the test conditions or when the HyperX reaches Mach 10. 00:20:25
How do you get HyperX to reach Mach 10? 00:20:32
The HyperX is attached to the nose of a rocket. 00:20:35
The rocket is mounted under the wing of a B-52 jet. 00:20:38
Let me explain what happens. 00:20:41
The B-52 takes the HyperX, which is attached to the rocket, up to a preset altitude and speed, and releases it. 00:20:43
Then, the rocket ignites and flies to an altitude of approximately 100,000 feet, traveling to the test conditions. 00:20:50
Next, the HyperX separates from the rocket and the scramjet engine ignites. 00:20:58
This is when the flight test begins. 00:21:03
The HyperX generates over 600 measurements that are sent to the control room during the flight. 00:21:06
These measurements allow the research engineers to determine the success of the flight. 00:21:11
Each engineer can access their data on specially designed displays, which are also recorded for post-flight analysis. 00:21:16
How do they analyze all these data? 00:21:23
Well, we use several different methods, but algebra is the foundation for all of these. 00:21:25
We use algebra throughout the design, flight testing, and post-flight analysis phases of the experiment. 00:21:30
The Vehicle Stability and Control System is a good example of how algebra is used during flight testing. 00:21:37
For example, take a seesaw. 00:21:43
A seesaw consists of a board and a pivot point, or fulcrum. 00:21:45
Suppose we have Norbert on one side of the seesaw and Zot on the other side. 00:21:49
Here, the seesaw is not balanced. 00:21:54
How do you balance the seesaw? 00:21:57
Well, to balance the seesaw, the product of the weight and the horizontal distance on the left side of the pivot point 00:22:00
must equal the product of the weight and the horizontal distance on the right side of the pivot point. 00:22:06
By moving Norbert on the left side of the pivot point closer in, you can see the seesaw becomes balanced. 00:22:11
In mathematical terms, the weight of Norbert times his horizontal distance to the pivot point 00:22:18
is equal to the weight of Zot times his horizontal distance to the pivot point. 00:22:23
Now, in the case of the HyperX, the flight computer controls the wings and the tails 00:22:29
to keep the vehicle flying and stable throughout the experiment. 00:22:34
Without these calculations, we wouldn't be able to fly and get the necessary data. 00:22:38
Have you flight tested the HyperX? 00:22:43
As a matter of fact, we did. 00:22:45
Unfortunately, like many experiments, this one didn't go as planned, 00:22:47
and the HyperX never made it to the test conditions. 00:22:51
Sometimes, when performing experiments, unforeseen events can occur. 00:22:54
However, we were able to receive data from the HyperX before the test was terminated. 00:22:59
We can use this data to successfully flight test the HyperX again 00:23:05
and achieve our mission of testing scramjet technology. 00:23:09
Wow, if the HyperX program is so successful, how will it affect the future of flight? 00:23:13
Well, let's see. 00:23:18
Recently, I flew from NASA Langley in Virginia to NASA Dryden here in California. 00:23:19
It took about five hours. 00:23:24
If the commercial aircraft were using the same technology used on the HyperX, 00:23:26
my flight time would have been reduced to 30 minutes. 00:23:31
If you ever plan to go into space, 00:23:34
the same technology would allow for larger cargo capacity, so space travel would cost less. 00:23:36
This technology would also allow for reusable vehicles at a much lower cost. 00:23:42
This means we could see more launches and more exploration of space. 00:23:47
Thanks, Lori. 00:23:56
For the next couple of minutes, we're going to take a look at a website 00:23:57
that will reinforce this show's hands-on activity you just saw. 00:24:00
It's called PlanMath, and it's produced by Info-Use in cooperation with NASA. 00:24:03
We're going to the Museum of Flight in Seattle, Washington, 00:24:08
where students from T.T. Minor Elementary School will help us show you 00:24:11
what the PlanMath website looks like. 00:24:14
From Dan's domain on the NASA Connect website, go to planmath.com. 00:24:17
Click on Activities for Students, then choose PlanMath Enterprises. 00:24:21
You'll need to visit each of the eight training departments. 00:24:25
Each section gives important information about aeronautical principles and terminology. 00:24:28
There are a number of geometry- and algebra-related math concepts, 00:24:33
and you'll also find plenty of interactive activities 00:24:36
that help you understand the concepts presented in the website. 00:24:39
The experts will guide you through training 00:24:42
as you prepare to design an airplane based on certain requirements. 00:24:44
When your training's complete, enter the Design Department, 00:24:48
where you meet your client before beginning the design process. 00:24:51
Then you'll design the size of your fuselage and wings. 00:24:54
The Building Department will make a prototype, which you'll test in a wind tunnel. 00:24:57
Based on these results, you'll choose an engine for your plane. 00:25:01
There will be a flight test to see if your plane can take off and reach its cruising speed. 00:25:04
If it succeeds in taking off, 00:25:09
you'll get results on how your plane flies under different conditions. 00:25:11
Based on your results, you can either make adjustments to your plane and retest it, 00:25:14
or present your design to your customers. 00:25:18
Well, that's PlanMath! 00:25:21
Special thanks to the Museum of Flight 00:25:23
and our AIAA student mentors from the University of Washington. 00:25:25
Teachers, if you would like a student mentor to help you in your classrooms, 00:25:29
find out more on the NASA Connect website. 00:25:32
Well, that wraps up another episode of NASA Connect. 00:25:38
We'd like to thank everyone who helped make this program possible. 00:25:41
Got a comment, question, or suggestion? 00:25:44
Email them to connect at larc.nasa.gov. 00:25:47
Or pick up a pen and mail them to NASA Connect, 00:25:52
NASA Center for Distance Learning, 00:25:55
NASA Langley Research Center, 00:25:57
Mailstop 400, 00:25:59
Hampton, Virginia, 23681. 00:26:01
Teachers, if you would like a videotape of this program 00:26:03
and the accompanying lesson guide, 00:26:06
check out the NASA Connect website. 00:26:08
From our site, you can link to the NASA Educator Resource Center Network. 00:26:10
These centers provide educators free access to NASA products, like NASA Connect. 00:26:14
From our site, you can link to CORE, 00:26:19
the NASA Central Operation of Resources for Educators. 00:26:21
For information about other NASA instructional resources, 00:26:24
visit NASA Quest at quest.nasa.gov. 00:26:28
So, until next time, 00:26:32
stay connected to math, science, technology, and NASA. 00:26:34
See you then! 00:26:38
I want the air to flow smoothly around them. 00:26:45
However, for the HyperX geometry, we require turbulent flow. 00:26:47
I screwed that up. 00:26:50
Let's try that one more time. 00:26:56
And now you have to work. 00:26:59
Here are the main objections. 00:27:12
Oh, I said that wrong. 00:27:14
And the objection is objective. 00:27:16
Today, I'm one of the... 00:27:18
I was that close, I was that close, that close, and I stumbled. 00:27:21
So, have you ever wondered what goes into designing an experimental X? 00:27:27
No. 00:27:32
No. 00:27:33
No. 00:27:34
Well, let's see. 00:27:35
Recently... 00:27:36
Too early. 00:27:37
It's the first airplane to fly into space. 00:27:40
Notice how closely it's shaped to a rocket. 00:27:43
There are tons of planes here. 00:27:46
Traveled, glide, and speed observations. 00:27:57
You will... 00:28:01
Oh, I'm sorry. 00:28:02
That's what I do when I'm nervous. 00:28:05
You're excited. 00:28:13
My belly itches. 00:28:16
My belly itches. 00:28:18
We're out of here. I have donuts. 00:28:19
Valoración:
  • 1
  • 2
  • 3
  • 4
  • 5
Eres el primero. Inicia sesión para valorar el vídeo.
Idioma/s:
en
Materias:
Matemáticas
Niveles educativos:
▼ Mostrar / ocultar niveles
      • Nivel Intermedio
Autor/es:
NASA LaRC Office of Education
Subido por:
EducaMadrid
Licencia:
Reconocimiento - No comercial - Sin obra derivada
Visualizaciones:
226
Fecha:
28 de mayo de 2007 - 16:53
Visibilidad:
Público
Enlace Relacionado:
NASAs center for distance learning
Duración:
28′ 28″
Relación de aspecto:
4:3 Hasta 2009 fue el estándar utilizado en la televisión PAL; muchas pantallas de ordenador y televisores usan este estándar, erróneamente llamado cuadrado, cuando en la realidad es rectangular o wide.
Resolución:
480x360 píxeles
Tamaño:
170.44 MBytes

Del mismo autor…

Ver más del mismo autor

EducaMadrid, Plataforma Educativa de la Comunidad de Madrid

Plataforma Educativa EducaMadrid
