Coming up on Destination Tomorrow, painless dentistry becomes a reality with a new dental 00:00:30

probe designed by NASA to detect periodontal disease. 00:00:41

We'll also see how future technologies might allow planes to fly like a bird. 00:00:45

And we'll meet the man who enabled efficient supersonic flight to become a reality. 00:00:50

All this and more, next on Destination Tomorrow. 00:00:54

Hello everyone, I'm Steele McGonigal. 00:01:01

And I'm Kara O'Brien, and welcome to Destination Tomorrow. 00:01:02

This program will uncover how past, present, and future research is creating today's knowledge 00:01:06

to answer the questions and solve the challenges of tomorrow. 00:01:11

We begin with an issue that affects all aircraft that fly in our atmosphere. 00:01:14

The formation of ice on airplanes is not only an issue on the runway during cold weather, 00:01:19

but can form on airplanes in flight. 00:01:23

This problem can be a dangerous situation for any piloted aircraft. 00:01:25

Fortunately, NASA has been conducting research on icing with a unique wind tunnel facility 00:01:29

that creates icing conditions on aircraft. 00:01:34

Jennifer Pulley takes Destination Tomorrow behind the scenes to see how this icing research 00:01:37

tunnel is helping engineers combat icing conditions on aircraft. 00:01:42

Thanks for the ice. 00:01:53

You know, there's nothing like a beverage chilled with ice during a long flight. 00:01:54

Inside an airplane, ice is something passengers desire. 00:02:01

However, outside an airplane, ice can be dangerous, especially if it forms on the wings or engines. 00:02:05

I had the opportunity to speak with Judy Foss-Vanzanti at the NASA Glenn Research Center in Cleveland, 00:02:11

Ohio. 00:02:17

She's researching the effects of icing on aircraft at a unique facility called the Icing 00:02:18

Research Tunnel. 00:02:22

Researchers at this facility study the formation of ice on the exterior of aircraft. 00:02:24

So while flying, the only ice you'll need to worry about is the ice inside your cup. 00:02:28

Well, I'm standing right here in the Icing Research Tunnel. 00:02:33

Right here, we create on Earth what it's like for an airplane to fly through an icing cloud 00:02:37

up there. 00:02:41

To do that, we've got to make it windy, cold, and wet. 00:02:42

Now, right now, I'm standing in front of the fan. 00:02:45

We have the fan to create the wind, and in the test section, which is a much smaller 00:02:48

cross-sectional area, we can get winds up to 400 miles per hour. 00:02:51

So that's about as fast as a plane might fly through in an icing environment. 00:02:55

We create the cold with our heat exchanger, 1,700 ton. 00:03:00

It can cool 500 homes. 00:03:03

That's how big it is. 00:03:05

We can get from zero Celsius down to about minus 20, which is where the icing might occur 00:03:07

in nature. 00:03:12

And we have spray bars. 00:03:13

The spray bars is what makes the icing tunnel. 00:03:16

We create the rain. 00:03:19

We create a mist that the airplane would fly through. 00:03:20

Now, the thing about the spray bars is the researchers need to control both how much 00:03:23

water is in the cloud, the liquid water content, we call it, and how big the drop size is. 00:03:28

And we have spray bars specially designed to create those conditions. 00:03:34

So in our test section, we create what it's like for an airplane to fly through an icing 00:03:37

cloud. 00:03:41

So why did NASA build an icing research tunnel? 00:03:42

As it turns out, during World War II, the Allies lost more aircraft to icing than enemy 00:03:46

fires. 00:03:53

They were trying to fly supplies over the Himalayas. 00:03:54

So the Air Corps turned to NACA, that's NASA's predecessor, and asked them to build an icing 00:03:56

research tunnel so we could understand what was going on and how to fix the problem. 00:04:01

So what do you test in the icing research tunnel, or the IRT? 00:04:05

What we test in the IRT is what makes sense to test. 00:04:09

Now, if you think about it, if you're in an airplane flying through an icing cloud, what 00:04:12

surfaces are most critical to keep ice free? 00:04:16

Well, it's the wings, which provide the lift, get you off the ground, and it's the engine 00:04:18

inlet, which provides the forward thrust. 00:04:23

So we typically can test just those components, just the wing or the engine inlet. 00:04:25

So what happens when ice forms on an airplane's wing? 00:04:30

Well, ice can disrupt the airflow over a wing and will eventually cause the airflow to separate. 00:04:34

This separation of airflow creates more drag and less lift. 00:04:41

If ice continues to form, the wing will no longer produce the appropriate amount of lift 00:04:46

needed to keep the airplane in flight. 00:04:51

In some cases, ice creates airflow separation over movable parts, like an aileron. 00:04:54

This could create handling or control problems, and the plane could suddenly roll. 00:05:01

As the wing is flying through the air, the ice only accumulates around the leading edge. 00:05:07

So that's why ice protection systems only wrap around the first part, the front part 00:05:11

of the wing. 00:05:15

The biggest factor in how the ice grows is temperature. 00:05:17

So if it's really cold, the water droplet comes in, hits the front part of the wing, 00:05:22

and freezes on impact, and you get this nice, pointy, rhyme shape. 00:05:26

The more dangerous ice comes during warmer conditions, those closer to freezing, where 00:05:30

the water comes in, hits the leading edge, and actually runs back a little bit. 00:05:35

If that happens, the next droplet might come in, see that droplet that is frozen, and start 00:05:39

to grow. 00:05:43

So you might get these ram's horns that grow upstream. 00:05:44

Now that significantly disrupts your airflow, and that is not, that's way off design, and 00:05:47

that's very bad. 00:05:52

Judy, tell me a little bit more about the icing protection system. 00:05:53

Do all planes have it? 00:05:56

There's what we call an anti-ice system, where you don't allow the ice to grow at all. 00:05:58

Ice, if you've got a very hot leading edge, you see that in jets, and there's a de-icing 00:06:02

system which has pneumatic boots, that the boots will wrap around that leading edge, 00:06:07

they'll inflate and pop the ice off, so you let the ice grow, and then you've got to get 00:06:12

it off. 00:06:15

The pneumatic boots are typically what you see with turboprop aircraft. 00:06:16

Does icing affect planes in, say, a warm climate? 00:06:21

Icing occurs everywhere. 00:06:25

You've got to be aware of it. 00:06:27

I've got a pilot friend who told me the worst icing he encountered was flying from Florida 00:06:29

to the Caribbean in July at 16,000 feet, the worst icing he ever saw. 00:06:34

But icing really can occur anywhere and anytime. 00:06:39

One of the things we do here at NASA is to have better designs, so maybe a system that 00:06:42

would automatically turn on the ice protection system if a sensor goes off. 00:06:47

The short-term solution is to train the pilots and educate them about how to detect icing, 00:06:51

how to be aware of it, train them how to get out of the icing environment if and when 00:06:57

they need to. 00:07:02

Ideally, icing is a non-issue in the future, and we're working to get there. 00:07:03

In 1987, the Icing Research Tunnel was designated an International Historical Mechanical Engineering 00:07:08

Landmark for its leading role in making aviation safer for everyone. 00:07:13

Coming up, we'll see how a new dental probe designed by NASA will make going to the dentist 00:07:17

a little easier. 00:07:22

But first, did you know that during World War II, the Allies lost nearly 1,000 planes 00:07:23

over the Himalayan Mountains due to icing? 00:07:28

Flight conditions here were so treacherous that pilots called this dangerous route the 00:07:31

Hump, or the Aluminum Trail. 00:07:34

When you hear the word dentist, what word immediately comes to your mind? 00:07:40

Pain? 00:07:44

Unfortunately, pain and dentistry have always been synonymous with each other. 00:07:45

Throughout history, dentists and engineers have attempted to make dentistry more comfortable 00:07:49

by making tools and equipment more patient-friendly. 00:07:54

Now NASA and its research partners have made pain-free dentistry a reality. 00:07:57

Jennifer Cortese examines how a new dental instrument, which was originally designed 00:08:01

at NASA, will finally make a trip to the dentist a painless experience. 00:08:05

Have you ever had this experience at your dentist? 00:08:12

It seems most people do not like to visit their dentist regularly. 00:08:21

Why? 00:08:25

Pain. 00:08:26

To some people, the sight of dental instruments often invokes feelings of anguish and fear. 00:08:27

In fact, most dental instruments are not pleasing to the eye, or to your mouth. 00:08:33

Until now. 00:08:38

NASA and its partners have developed an instrument that will help keep periodontal disease, which 00:08:39

is the leading cause of tooth loss in adults, in check. 00:08:43

This technology was originally designed to help detect cracks in airplanes, but is now 00:08:47

currently being used to design and manufacture a revolutionary dental instrument called the 00:08:51

Ultrasonographic Periodontal Probe. 00:08:56

The technology that's in the probe is ultrasonics. 00:08:59

These are the sound waves that we use to probe inside materials, such as the aircraft wings. 00:09:03

Ultrasonics is very high-frequency sound. 00:09:10

We at NASA use high-frequency sound to actually look inside materials. 00:09:14

We like to be able to assess the health of a material, just like a physician would assess 00:09:19

the health of a person. 00:09:25

When you look with ultrasound inside a material, you can find defects. 00:09:27

Defects such as internal damage. 00:09:33

Defects such as corrosion that would lead to a loss of strength of a material that might 00:09:36

cause a mission failure. 00:09:42

Now, how did you discover the specific problems that the probe solves? 00:09:44

The specific problem was actually discovered while we were trying to assess the integrity 00:09:48

of aircraft. 00:09:54

Ultrasonics could characterize the desponds and micro-cracking that occurred near rivets 00:09:56

on aircraft. 00:10:01

That same ultrasonics could be used to find desponds between the teeth and the gums. 00:10:03

In other words, periodontal disease. 00:10:09

Periodontal disease is an infection of the tissues that help anchor your teeth. 00:10:12

If left untreated, it can lead to tooth and bone loss. 00:10:16

Currently, the most widely performed method to measure periodontal disease is not the 00:10:18

most comfortable. 00:10:23

It involves the insertion of a small, blunt probe between your tooth and gum to measure 00:10:24

the depth of the periodontal pocket. 00:10:29

This process is highly invasive, uncomfortable, and inconsistent. 00:10:31

This new instrument, developed by NASA Langley and its partners, uses ultrasonic sound waves 00:10:36

that interact with your teeth and map the periodontal pocket. 00:10:40

NASA works very closely with medical people during the technology transfer that allows 00:10:45

us to take what we have learned in studying materials and apply it to materials that are 00:10:52

human tissue. 00:10:57

We've had many people contribute to its success. 00:10:59

One of those individuals is John Companion. 00:11:02

John worked at NASA Langley Research Center for 27 years and now works in the Applied 00:11:05

Science Department at the College of William and Mary. 00:11:09

We met up with John at the Dental Hygiene Research Center at Old Dominion University. 00:11:12

The new probe simply touches the surface of the gum and slides along. 00:11:17

The only coupling between the gum and the probe is just water. 00:11:23

So it's totally non-invasive, doesn't hurt at all, should provide more information because 00:11:26

of the way the information is gathered, and it should be faster. 00:11:33

The problem that you have with the current technology is one, obviously, that's highly 00:11:38

invasive and this hurts. 00:11:42

Ultrasound doesn't. 00:11:45

No sensation, no penetration. 00:11:46

They simply run it just along the edge of the gum and you get a nice little image on 00:11:49

the screen of a computer that shows you a map. 00:11:54

All the information retrieved by the probe can be archived on a computer. 00:11:57

A physician can then compare real-time data and past data to diagnose the condition of 00:12:01

the patient. 00:12:06

And the nice thing that dentists like about this is they can show the map to the patient 00:12:07

so we can actually see what's going on in the gum. 00:12:13

And of course, if you can evaluate the disease, you can also evaluate the treatment. 00:12:17

So when they start treating it, you can go back and you can check on it and see is this 00:12:22

particular treatment doing any good, do we need to modify it, do we need to do something 00:12:26

different here. 00:12:30

And because this will all be computerized, you only need one person to do it. 00:12:31

Right now you have to have one person to take the measurement, one person to write down 00:12:35

the measurement. 00:12:38

There's time savings, there's money savings. 00:12:39

Patients like it. 00:12:43

I liked it. 00:12:44

I've actually used myself as a guinea pig. 00:12:45

I've had all three types of probing done by several different dentists now and let 00:12:47

me tell you, the ultrasound is the only way to go. 00:12:52

The use of ultrasound in dental diagnostics provides an alternative approach to conventional 00:12:55

probing. 00:12:59

Patient discomfort and the need for drugs like Novocain are virtually eliminated. 00:13:01

This technology could eventually touch every person who visits the dentist regularly. 00:13:05

Today many planes break the sound barrier with relative ease, but it wasn't too many 00:13:14

years ago that the sound barrier was just that, a seemingly impenetrable invisible wall. 00:13:19

In fact, many aerodynamicists thought that the sound barrier may never be broken by man 00:13:25

until one man named Richard Whitcomb developed a theory called area rule that enabled efficient 00:13:30

supersonic flight to become a reality. 00:13:36

Before October of 1947, attempts to break the sound barrier usually ended in disaster. 00:13:40

That was until Chuck Yeager and the X-1 flew through the sound barrier on October 14, 1947. 00:13:46

The sound barrier had finally been broken. 00:13:52

But there it was what I call a brute force approach in the sense that your rocket just 00:13:55

rammed that airplane through the speed of sound, but the drag was so high that they 00:14:00

used up all the fuel in just about five minutes. 00:14:05

So it was not practical supersonic flight, but it did accomplish breaking of the barrier. 00:14:08

There needed to be a more efficient way to break the speed of sound. 00:14:14

Dick Whitcomb set out to find a way. 00:14:18

Whitcomb found that when a plane reached near supersonic speeds, the drag around the wings 00:14:20

would increase by as much as a factor of five. 00:14:25

He saw that much like a bullet, the fuselage was extremely aerodynamic without the wings, 00:14:28

but when the wings were added, an aerodynamic bump was causing incredible amounts of drag 00:14:34

that was slowing the plane down. 00:14:39

It became obvious to him that he had to find a way to take the bump out of the equation. 00:14:42

Whitcomb's tests showed that when he added the entire area of wings and fuselage together, 00:14:47

the drag, or aerodynamic bump, was exactly the same as the drag of a fuselage with wings. 00:14:52

He worked tirelessly to find a solution, when one day, as he was thinking about the problem, 00:14:59

the solution hit him like a bolt of lightning. 00:15:04

He must indent, or pinch in, the waste of the fuselage. 00:15:07

This new shape of the fuselage would closely resemble the shape of a Coke bottle. 00:15:12

Whitcomb was astonished to find that by changing the shape of the fuselage, he took the bump 00:15:17

out of the equation and allowed the plane to become as aerodynamically smooth as a fuselage 00:15:22

without wings. 00:15:27

This very simple fix came to be known as the area rule. 00:15:29

I had the idea, then we built some models to try and demonstrate it. 00:15:33

We built airplanes with Coke bottle shaped fuselages, and lo and behold, the drag of 00:15:38

the wing just disappeared. 00:15:46

Now there was when I was really thrilled. 00:15:47

That was far, that was a year or two before anything flew, but there the wind tunnel showed 00:15:51

that it worked perfectly. 00:15:56

It was not some oddball theory, it was a practical means of reducing drag. 00:15:59

When the area rule concept was flight tested on the newly converted F-102 fighter, the 00:16:05

plane soared through the sound barrier with ease. 00:16:10

Whitcomb's discovery revolutionized the way that supersonic fighters, bombers, and transports 00:16:14

were built from the 1950s through today. 00:16:19

In fact, the area rule concept is still used on many modern planes, including the B-1 bomber 00:16:21

and the Boeing 747. 00:16:27

Dick Whitcomb's intuition and daring led to a revolution in air technology that has forever 00:16:30

changed the history of flight. 00:16:35

For his effort in developing the area rule concept, Dr. Whitcomb won the prestigious 00:16:40

Collier Trophy, which is awarded annually for great achievement in aeronautics and astronautics 00:16:44

in America. 00:16:48

Coming up, we'll see how NASA researchers are working on a morphing technology that 00:16:50

will allow future aircraft to fly like birds. 00:16:54

But first, did you know that Jacqueline Cochran was the first woman to break the sound barrier? 00:16:56

Cochran broke the barrier May 18, 1953 in an F-86 Sabre jet. 00:17:01

At the time of her death in 1980, she held more speed, altitude, and distance records 00:17:06

than any other pilot, man or woman, in history. 00:17:12

Imagine how most people felt the first time they heard that one day man would be able 00:17:20

to fly, or that we hope to actually land a man on the moon. 00:17:26

Those ideas seemed pretty crazy at the time, but today we know just about anyone can fly 00:17:30

in an airplane, and we have astronauts actually living in space. 00:17:34

Now, what if I told you that one day we would be able to fly in an aircraft that could bend, 00:17:39

twist, and maneuver just like a bird? 00:17:44

Sound crazy? 00:17:47

Well, I spoke with Anna McGowan at the NASA Langley Research Center, who's working to 00:17:48

incorporate something called morphing technology into aircraft. 00:17:52

And these morphing technologies could turn those crazy ideas into reality. 00:17:56

Morphing is looking at really advanced materials and other technologies that will make airplanes 00:18:02

even better than they are today. 00:18:07

We got the word morphing actually from the word metamorphosis. 00:18:08

The word morph means to change, and we're using a lot of advanced materials and technologies 00:18:13

to make airplanes change from one configuration to the other. 00:18:18

Our task at NASA Langley is to look 20 years into the future. 00:18:23

Some of our challenges are making the airplanes even safer, making them more efficient, meaning 00:18:26

you could fly farther on the same tank of fuel, or carry more passengers, for example. 00:18:31

And we're working on making airplanes as versatile as a bird is. 00:18:37

So we're taking some lessons from nature. 00:18:41

To get aircraft to perform with bird-like agility, first you have to understand how 00:18:44

birds fly. 00:18:49

Efficient wing design, feathers, and hollow, lightweight bones allow birds to fly better 00:18:50

than any man-made machine. 00:18:55

By drawing on the inspiration of birds, Langley researchers are hoping to develop technologies 00:18:57

that will enable aircraft to perform with bird-like agility. 00:19:02

For example, synthetic jets will cover parts of the wing and replicate the effects of feathers. 00:19:06

These technologies can alter the airflow over the wings for superior maneuverability. 00:19:12

Microspheres will replicate the bird's hollow bones and allow lightweight wings to be manufactured 00:19:17

for increased performance and efficiency. 00:19:24

Sounds like science fiction, but in fact, these technologies are real. 00:19:26

We make airplanes as efficient as birds by trying to replicate or mimic some of the characteristics 00:19:31

birds have. 00:19:36

As an example, birds use feathers to control the airflow over the wings. 00:19:37

We are doing that by using what are called synthetic jets. 00:19:42

Synthetic jets suck in their own air and then pump it out very quickly, creating a fluctuating 00:19:45

plume of air. 00:19:51

This little plume of air basically simulates what a feather would do. 00:19:52

On a bird, the feathers are used to adjust the airflow over the wing of the birds so 00:19:56

that the bird flies optimally no matter what the air conditions are outside. 00:20:02

Now, on an airplane, we do the same thing. 00:20:06

We put these jets inside the wing of the airplane and say, for example, we had a gust 00:20:08

of wind coming into the airplane. 00:20:12

We would turn on very specific jets at the right time and at the right frequency. 00:20:14

And by doing so, then we can adjust the airflow over the wings of the airplane, thereby making 00:20:19

the airplane very stable and comfortable and maneuverable at all flight conditions. 00:20:23

We also want to be able to mimic the porous inside section of a bird bone because that 00:20:28

porous inside section is lightweight, but it adds extra strength. 00:20:33

We do that by using what are called tiny microspheres. 00:20:38

You would take these microspheres and actually inject them into a composite material. 00:20:42

And once we inject them in, we would use heat to fuse them together. 00:20:47

So therefore, we could achieve a lightweight structure that is also very strong, which 00:20:51

is the same thing that birds use when they fly. 00:20:56

Anna, besides birds, are there any other designs inspired by nature? 00:20:58

Well, we're also looking to the water for some inspiration from nature. 00:21:02

Fish and shark and whales swim very efficiently in the water. 00:21:06

And the flow of water over the skin of a shark is very similar to the flow of air over the 00:21:11

wings of an airplane. 00:21:16

If you look at shark skin under a microscope, you'll actually see a bunch of little teeny 00:21:17

grooves. 00:21:21

So our hope at NASA Langley is that perhaps our material scientists can create the same 00:21:22

groove-like material and we can apply that to the skin of airplanes and make them much 00:21:27

better flyers. 00:21:31

We're also looking at flapping wing airplanes, believe it or not. 00:21:33

This design was inspired by the wings of a hummingbird. 00:21:37

If you use an airplane that does not have flapping wings, you have to have two things, 00:21:39

an engine and wings. 00:21:44

Flapping wing airplanes do not need an engine. 00:21:46

The wings will provide you forward motion or thrust, as well as lift, which goes up. 00:21:48

So Anna, tell me how you design a flapping wing without using an engine. 00:21:53

We actually use what are called smart or active materials instead of using an engine. 00:21:57

And why is it referred to as smart material? 00:22:03

Well smart materials actually move on command. 00:22:05

These are materials that when you apply a stimulus, like electricity or heat or in some 00:22:08

case magnetism, they actually move. 00:22:13

Another very common one that we've just developed is called a macrofiber composite. 00:22:15

The macrofiber composite works by when you apply electricity to it, it will move in the 00:22:21

direction you'd like it to move. 00:22:25

So what we would do is when we adhere this, or if you were embedded inside an airplane 00:22:27

wing or the tails of a fighter airplane, it would actually absorb the vibration. 00:22:32

As a consumer, you can put these in your washing machine to absorb vibration. 00:22:37

You can put it in your cars. 00:22:40

You can even use it to absorb sound. 00:22:41

So we think that these materials like this one are really going to revolutionize how 00:22:44

we build things in the future. 00:22:48

We're also looking at a material called a shape memory alloy. 00:22:50

We would use this material to bend and twist airplane wings. 00:22:53

Now you might wonder why we'd want to do that kind of thing. 00:22:56

Well birds also bend and twist their wings in flight. 00:22:59

Now being able to bend and twist airplane wings is really difficult because airplane 00:23:03

wings tend to be very stiff. 00:23:07

If you bend this material, this shape memory alloy, it will actually go back to its original 00:23:09

shape. 00:23:14

So if you bend this, I'll show you what it looks like. 00:23:15

Now I'm going to apply this lighter to it, and you can watch it go back to its original 00:23:19

shape. 00:23:23

Now this simple little material can pull around 700 pounds. 00:23:24

So by placing a couple of these in an airplane wing, we can make the airplane bend or twist. 00:23:29

We hope that by flying more like a bird does, we can save a lot of money on fuel, as well 00:23:35

as reduce the complexity of the mechanisms within the airplane wing. 00:23:40

So we're using a lot of these biologically inspired materials and technologies to make 00:23:43

aircraft and spacecraft a lot safer to fly. 00:23:48

Ground and wind tunnel testing are currently underway in the morphing program to bring 00:23:53

these fascinating technologies to fruition. 00:23:57

Sensor technologies have been around for quite some time. 00:24:00

In fact, sensors are virtually everywhere. 00:24:03

But what are they? 00:24:06

And how do they work? 00:24:07

For some answers, we turn to Johnny Alonzo. 00:24:08

Sensors. 00:24:17

Sensors. 00:24:18

Sensors. 00:24:19

Sensors. 00:24:20

Sensors. 00:24:21

Sensors. 00:24:22

They're just about everywhere. 00:24:23

Most people probably couldn't live without them. 00:24:24

Have you ever slammed a snooze bar on your alarm, opened your garage with a remote control, 00:24:25

set your car alarm, or changed the channels on your television with a remote? 00:24:27

Sure you have. 00:24:31

They're all controlled by sensors. 00:24:32

With today's technology, most sensors are extremely small or invisible to the naked 00:24:34

eye. 00:24:38

Heat, light, sound, pressure, or a particular motion can trigger a sensor to perform a specific 00:24:39

action. 00:24:46

There are sensors in our cars, our homes, offices, even in our own bodies. 00:24:47

But what exactly is a sensor? 00:24:52

And how does it work? 00:24:54

For some answers, I spoke with Dr. Gary Gibbs at NASA Langley Research Center. 00:24:56

A sensor is a device that detects physical phenomena such as light, heat, air flow, pressure, 00:25:00

temperature, even sound. 00:25:06

And generally speaking, how do sensors work? 00:25:08

They work through a mechanism called transduction, where we're converting one form of energy 00:25:10

into another. 00:25:14

Maybe a form of energy that's less useful into, say, electrical energy. 00:25:15

And an example would be like a solar cell, where it takes energy from the sun and converts 00:25:20

it into electrical energy that we can use. 00:25:24

All sensors utilize transduction to convert energy such as light or heat into typically 00:25:26

electrical energy. 00:25:31

Another example might be a telephone button, which when pressed, converts mechanical energy 00:25:32

from your finger into an electrical signal in the form of a tone. 00:25:36

So Gary, what are some typical examples of sensors that we use every day? 00:25:41

Sensors are around us everywhere. 00:25:45

In fact, when we go to the grocery store, there's barcode scanners to detect the barcodes 00:25:46

on products we buy. 00:25:50

In fact, in our car, there's sensors to detect a crash, to open airbags. 00:25:51

And in fact, the telephones that we use every day have sensors called microphones that sense 00:25:56

the sound of our voice. 00:26:01

So it would be safe to say that there are millions of sensors out there, right? 00:26:02

Absolutely. 00:26:06

Really? 00:26:07

Do they all work the same? 00:26:08

No, they actually work quite differently. 00:26:09

We've got quite a few examples of microphones today, and they were designed for different 00:26:11

reasons. 00:26:14

In fact, the first item we see here is an ancient telephone from the 50s. 00:26:15

I love it. 00:26:18

And you can see here a typical microphone from a CB radio or intercom type system. 00:26:19

Sure. 00:26:25

In fact, this is a microphone like you might see on your home computer, and we have a cell 00:26:26

phone here that even has a very tiny microphone that senses the sound of your voice. 00:26:30

And they all sense the same kind of phenomenon, but each one is designed specifically for 00:26:34

a particular purpose. 00:26:38

They're all configured quite differently. 00:26:40

So a microphone is a sensor? 00:26:42

Yes. 00:26:44

Okay. 00:26:45

So how does a microphone sense sound? 00:26:46

Well, we have a laboratory-grade microphone here connected to an oscilloscope, which is 00:26:47

a device that shows the electrical signal produced by the microphone. 00:26:51

And you can see when I whistle, it displays a sine wave. 00:26:56

A microphone is constructed with two plates, one thick and one thin, and the sound from 00:27:01

our voice, for example, strikes the thin plate, causing it to vibrate. 00:27:05

That vibration produces an electrical signal similar to what we saw in the oscilloscope. 00:27:10

Okay, so earlier I mentioned biological similarities between sensors and human senses. 00:27:13

Right. 00:27:19

Okay. 00:27:20

How is a microphone similar to the human ear? 00:27:21

That's pretty interesting, because sound travels through the ear until it strikes the eardrum, 00:27:22

causing it to vibrate, similar to the plates in the microphone we talked about earlier. 00:27:27

This vibration is transferred through tiny bones to the cochlea, which contains small 00:27:32

hair follicles that vibrate, producing an electrical impulse, similar to the microphone. 00:27:37

So the hair follicles are like sensors? 00:27:42

Yes. 00:27:44

Well, Gary, thanks for your time and for showing us how sensors work. 00:27:45

Sure. 00:27:47

Thanks for coming out to the National Atlantic Research Center. 00:27:48

No problem, man. 00:27:49

No problem. 00:27:50

I guess that's a wrap. 00:27:51

Hey, is this thing still on? 00:27:52

Sure. 00:27:53

Yeah. 00:27:54

Thanks for joining us on this edition of Destination Tomorrow. 00:27:55

I'm Steele McGonigal. 00:27:58

And I'm Kara O'Brien. 00:27:59

And for all of us here at NASA, we'll see you next time. 00:28:00

Valoración:

Eres el primero. Inicia sesión para valorar el vídeo.

Idioma/s:

Niveles educativos:

▼ Mostrar / ocultar niveles

- - Nivel Intermedio

Autor/es:

NASA LaRC Office of Education

Subido por:

EducaMadrid

Licencia:

Reconocimiento - No comercial - Sin obra derivada

Visualizaciones:

618

Fecha:

28 de mayo de 2007 - 17:04

Visibilidad:

Público

Enlace Relacionado:

NASAs center for distance learning

Duración:

28′ 32″

Relación de aspecto:

4:3 Hasta 2009 fue el estándar utilizado en la televisión PAL; muchas pantallas de ordenador y televisores usan este estándar, erróneamente llamado cuadrado, cuando en la realidad es rectangular o wide.

Resolución:
