we are going to describe some electric components the more important that we
00:00:02
are going to use obviously and some of them such as resistors just only
00:00:09
control the values of the current electrical current but they can also use
00:00:21
as inputs in an electronic circuit if there are variable resistors or
00:00:31
potentiometers because they can transform the position so a physical
00:00:40
physical action into a current something that happens in the current
00:00:52
Buzzers are also outputs, they emit sounds, lamps are also outputs, they can bright, and fuses are protection elements,
00:01:00
And switches are to control the circuit and the way it works.
00:01:22
The resistor. The resistor limits the flow of electrical current through the circuit by using the Ohm's law.
00:01:31
But the value of the resistors can be different and we can know by using the color code.
00:01:43
A resistor such as this usually has at least four rings, four bands.
00:01:55
three has different color and the fourth one just only be a gold or silver
00:02:05
so we can know the value of the resistor by using this code it is very easy to know
00:02:15
The band 1 and 2 are just only digits and the value of this digit is known by its color.
00:02:28
Black is 0, brown is 1, red is 2, orange 3, yellow 4, green 5, blue 6, violet 7, grey 8 and white 9.
00:02:46
So, you can know the values, two digits. And the third one is an exponent of something. So, it's connected to the multiply of the value.
00:03:03
and the value of this exponent is known by its color
00:03:26
so for example if you have something brown, brown, brown
00:03:36
is 11, but you should multiply by 10
00:03:43
So it will be 110. And the fourth band is just only the tolerance. If it's gold, it's the 10% of the main value.
00:03:53
Sorry, it is silver, it is the 10% of the value, and it is gold, it is the 5% of the value.
00:04:11
As you can see in this example, for example, you can see here, you can see some example.
00:04:23
The resistors can also have more than four bands, such as 5-oxys, and this is a little bit more complicated in this particular case.
00:04:35
You can see some examples, 3-3, in this example, for example, 3-3 because it's orange, orange, orange, and it is multiplied by 2.
00:04:53
so if they either could be no it is you can also have a variable resistance of
00:05:22
potentiometers in this particular case the connection the resistance the
00:05:50
resistance can be different because we can change the length of this resistance
00:05:57
so by the connection it was it usually have three connections and what and the
00:06:06
real connection in the circuit is one and two so you have the the output one
00:06:15
and the output into and the resistance and can be calculated by this one the
00:06:22
so it depends of its length research are other other electric components they
00:06:31
emits a blue scene when the current flow and it has polarity so you should be
00:06:46
careful when you connect them both are very useful because they are really
00:06:54
important and in a bulb you have the you have a distant filament which which by
00:07:05
Joule's effect heats a lot and it emits light when the heat is enough
00:07:17
this is its symbol just only to protect something generally a component by Joule's
00:07:30
effect the filament always heats so if the heat is enough the filament can melt and then the current
00:07:44
flow the flow is stopped it is the same as a switch open for control it can be different types
00:07:58
it just only have to position open and close one that can allow let the current flow flows can be
00:08:11
one switch or just a push and the other the other types other types is when has
00:08:31
two or more or more ways that it is usually used to different
00:08:41
controls. Limit switches which is a device that works between different
00:08:50
position by a lever or so on and I hope it can be useful
00:09:00
