To use electricity, we need to find a way to safely contain and control this flow of charged particles.
00:00:00
That is what a battery cell does.
00:00:07
A battery is a chemical device capable of converting stored chemical energy into electrical energy.
00:00:09
As you know, batteries have two terminals or ends labeled plus and minus.
00:00:17
This reflects the negative and positive charges on electrons and protons.
00:00:22
The chemistry of a battery creates a force that moves electrons out of the metal plate on the negative end
00:00:26
and attracts them to the metal bump on the positive end.
00:00:36
Electrons will start to move from minus to plus if the right kind of material is connected to the battery.
00:00:40
Materials that allow electricity to travel through them are called conductors.
00:00:48
Most metals are good conductors of electricity.
00:00:53
Copper is the most common metal used in wires.
00:00:56
In this animation, a conductor is connected to each terminal of a battery.
00:01:02
Electrons start to move, traveling from the negative terminal towards the positive terminal.
00:01:07
This is electricity.
00:01:13
The electrons actually move from atom to atom as they travel through the conductor.
00:01:15
This is a safety warning.
00:01:21
Never connect a short metal wire between the terminals of a battery.
00:01:23
This is a short circuit. The wire will get hot, you might burn yourself, and the battery will quickly lose its energy.
00:01:27
Have you noticed the letter V on the side of a battery?
00:01:36
This represents volts. Volts, or voltage, is a measure of the force moving the electrons.
00:01:39
A AA battery is usually 1.5 volts.
00:01:47
This is a low voltage, and that is why it is safe to handle a AA battery.
00:01:51
Higher voltages are dangerous. Never experiment with anything that plugs into a wall outlet.
00:01:56
Wall outlet voltages range from 120 volts to 240 volts. Extremely dangerous.
00:02:03
