Destination Tomorrow - DT3 - Helicopters
Ajuste de pantallaEl ajuste de pantalla se aprecia al ver el vídeo en pantalla completa. Elige la presentación que más te guste:
NASA Destination Tomorrow Segment describing how helicopters work and the different types of helicopters in use.
Some initial milestones for the Aviation Systems Capacity Program have already been accomplished
00:00:00
and are currently being tested for future use in airports.
00:00:05
We've all seen helicopters flying around, but do you know how they work?
00:00:09
For some answers, we turn to Johnny Alonzo.
00:00:12
For over 60 years, the helicopter has been one of the most versatile types of transportation around.
00:00:30
It has the ability to fly forward, backwards, sideways, rise and descend vertically, and hover motionless in the air.
00:00:48
Helicopters have been credited with saving over 3 million lives by transporting critically wounded people from accidents and war zones.
00:00:56
They're also used for things like helping the police fight crime, fighting forest fires, and simple tasks like checking our roadway conditions.
00:01:02
But have you ever wondered how helicopters fly?
00:01:09
For some answers, I spoke with NASA Langley researcher Mike Watts at the Coast Guard Air Station, Elizabeth City.
00:01:12
Johnny, to really understand how a helicopter flies, first let's go back to a fixed wing world, a regular airplane, the kind with wings and an engine.
00:01:23
Now, a fixed wing has an engine, a jet, or a propeller to push you through the air.
00:01:32
And that moves air over the wings, which provides lift that keeps it in the air.
00:01:37
And obviously from this helicopter, you can see we don't have normal wings, and we don't have a jet or a propeller on it to push you forward through the air.
00:01:42
But what you do have is the main rotor blades.
00:01:50
You can notice that these are shaped a lot like wings for a fixed wing.
00:01:53
The way you get them moving through the air is these rotate around in a circle, and that moves them through the air.
00:01:57
They're shaped just like a wing, so that provides a lift force that lifts the helicopter off the ground.
00:02:03
Cool. So you've tapped in on how a helicopter lifts off the ground.
00:02:09
Can you explain to me how you control the altitude?
00:02:13
Sure. The way you control the altitude is by generating more lift, a more upward force.
00:02:16
And the way you do that is you pitch the rotor blade to a higher angle in relation to the wind.
00:02:21
That generates more lift, and that lifts it off the ground.
00:02:26
To go down, you just reduce the angle of the blades. That generates less lift, and gravity settles you down into the ground.
00:02:29
So this is the main rotor. What is this?
00:02:36
This is called a tail rotor.
00:02:39
As you can see, it looks like a main rotor or a propeller on its side.
00:02:42
When you turn the main rotor blades, the body of the helicopter wants to go against the rotation.
00:02:47
So if the blades are turning this way, the body wants to go this way.
00:02:52
Well, to keep straight, you have to provide something to counter that turn, that force pushing it sideways.
00:02:55
So we provide a force that keeps it straight, and that's what the tail rotor provides.
00:03:00
Wow.
00:03:05
If you want to go to the left, you provide more force, and it goes this way.
00:03:06
If you want to go to the right, you provide less force, and the torque turns it this way.
00:03:09
So, Mike, you briefly explained to us how you keep the helicopter straight.
00:03:13
How do you make it go forward?
00:03:16
Well, you make it go forward by providing a force to push it forward.
00:03:18
Just like in a regular airplane that has a propeller, the propeller is providing a force to push the airplane forward.
00:03:23
We need to provide that somewhere.
00:03:29
If you think of the main rotor as a disc in the air, and it's got a force going through the center of it,
00:03:31
that's what we talked about as a thrust, that holds it in the air.
00:03:36
If you tilt it forward a little bit, it's going to pull the helicopter forward.
00:03:40
If you tilt it back, it's going to pull the helicopter back.
00:03:45
If you want to go sideways, you just tilt it to the side, and it pulls you sideways like that.
00:03:48
So you have the force pulling you backwards, forwards, and sideways.
00:03:53
And if you actually take that disc and turn it all the way on its side,
00:03:58
it's like the propeller is pulling you all the way forwards.
00:04:02
And there's a concept being looked at by the Marines now called the V-22 tilt rotor,
00:04:04
and that is to turn the rotors on their sides and make them propellers.
00:04:09
You get the benefits of going farther and faster with a fixed wing than a regular airplane,
00:04:13
and you can take off and land vertically, just like a helicopter.
00:04:17
That's all there is to it.
00:04:21
That's all there is to it.
00:04:22
That's all there is to it.
00:04:23
Mike, thanks for coming out and showing us everything about helicopters.
00:04:24
My pleasure, my pleasure.
00:04:27
You got the keys, man?
00:04:28
Oh, yeah, let's go fire it up.
00:04:29
Come on, let's do it.
00:04:30
All right, let's go.
00:04:31
So that's how it works.
00:04:33
I'd like to thank the U.S. Coast Guard for letting us use their facilities here in the listening city.
00:04:35
I think we're taking off now.
00:04:39
Let's go to my house.
00:04:41
Where are we going to park?
00:04:42
